Lexus GX J120 (2002-2009) tail batt sttl b/up sttr gnd brk 2 3 4 5 6 7 wiring diagram

1 2 3 4 5 6 7 8 9 +B RTOT RTIN LTOT ACC CUT RELAY BATT CHG FUSE BATT CHG RELAY BLK WIRE BLK/RED WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BLU/RED WIRE BLU/YEL WIRE BODY ECU BRN WIRE DAC RELAY DRIVER SIDE J/B (BEHIND LOWER LEFT END OF DASH) EB (ON LEFT FRONT INNER FENDER) ENGINE CONTROLS SYSTEM ENGINE ROOM R/B (ON LEFT SIDE OF ENGINE COMPARTMENT) ENGINE ROOM R/B 4 (ON LEFT SIDE OF ENGINE COMPARTMENT) GRN WIRE GRN/RED WIRE GRN/YEL WIRE GRY WIRE GRY/BLU WIRE HOT AT ALL TIMES JUNCTION CONNECTOR 19 (RIGHT SIDE OF DASH) JUNCTION CONNECTOR 2 JUNCTION CONNECTOR 30 (LEFT REAR OF VEHICLE, BEHIND BUMPER) JUNCTION CONNECTOR 31 (LEFT REAR OF VEHICLE, BEHIND BUMPER) JUNCTION CONNECTOR 32 (LEFT REAR OF JUNCTION CONNECTOR 7, 8 (LEFT END OF DASH) LT GRN WIRE RED WIRE RED/BLK WIRE RED/YEL WIRE SKID CONTROL ECU (W/ ACTUATOR) (LEFT REAR OF ENGINE COMPT) STIN LTIN STOP FUSE TAIL BATT STTL B/UP STTR GND BRK 2 3 4 5 6 7 TOWING BRAKE FUSE TOWING CONVERTER RELAY (ON LEFT SIDE OF CARGO AREA) TOWING FUSE TOWING TAIL RELAY TRAILER SOCKET TURN, HAZ FUSE VEHICLE, BEHIND BUMPER) BP WHT WIRE WHT/BLK WIRE YEL WIRE
