Lexus GX J120 (2002-2009) passenger air bag on/off indicator, seat belt warning light Wiring diagram
This page shows the only wiring diagram for the component.passenger air bag on/off indicator, seat belt warning light, which is found in the car Lexus GX J120 (2002-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger air bag on/off indicator, seat belt warning light (1 of 1)
A/T SHIFT INDICATOR
ACAN
BLU WIRE
BLU/WHT WIRE
BODY ECU
BRN WIRE
CANADA
COMBINATION METER
COMBINATION SWITCH
DOME FUSE
DRIVER SIDE J/B (BEHIND LOWER LEFT END OF DASH)
EG (REAR OF LEFT CYLINDER HEAD)
ENGINE ROOM R/B (ON LEFT SIDE OF ENGINE COMPT) J/B FUSE
FUSE
GRN WIRE
GRN/RED WIRE
GRY WIRE
GRY/BLU WIRE
HEATER CONTROL SWITCH
HOT AT ALL TIMES
HOT IN ON OR START
IG ILL- TR
IJ (BEHIND LEFT CENTER OF DASH)
ILEW
ILLUMINATION
J/B 1 (BEHIND CENTER OF DASH)
J/B 2 (BEHIND CENTER OF DASH)
J/B 3 (BEHIND RIGHT SIDE OF DASH)
JUNCTION CONNECTOR 11 (LEFT END OF DASH)
JUNCTION CONNECTOR 14 (LEFT SIDE OF DASH)
JUNCTION CONNECTOR 19 (RIGHT SIDE
JUNCTION CONNECTOR 19 (RIGHT SIDE OF DASH)
OF DASH)
OFF HEAD TAIL LIGHT CONTROL SWITCH
PANEL FUSE GAUGE FUSE
PASSENGER AIR BAG ON/OFF INDICATOR, SEAT BELT WARNING LIGHT
RED WIRE
RED/BLU WIRE
RHEOSTAT
SUB BODY ECU (BELOW LEFT "D" PILLAR, BEHIND TRIM)
TAIL
TAIL IND
TAIL RELAY
WHT WIRE
WHT/BLK WIRE
WHT/GRN WIRE
Go to component -> Instrument illumination circuit, with navigation (1 of 2) -> PASSENGER AIR BAG ON/OFF INDICATOR, SEAT BELT WARNING LIGHT
