Lexus GX J120 (2002-2009) off lo hi Wiring diagram

10 11 14 SIG BECU SPD BLK WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BLU/RED WIRE BODY ECU (BEHIND LEFT END OF DASH) BQ (AT CENTER REAR OF HATCH) BRN WIRE COMBINATION METER COMBINATION SWITCH DOME FUSE DRIVER SIDE J/B (BEHIND LOWER LEFT END OF DASH) ECU-B FUSE ECU-IG FUSE EG (ON REAR OF LEFT CYLINDER HEAD) ENGINE ROOM R/B (ON LEFT SIDE OF ENGINE COMPT) GAUGE FUSE GRN WIRE HOT AT ALL TIMES HOT IN ON OR START J/B 1 (BEHIND CENTER OF DASH) J/B 2 (BEHIND CENTER OF DASH) JUNCTION CONNECTOR 11 (LEFT END OF DASH) IH JUNCTION CONNECTOR 14 (LEFT SIDE OF DASH) JUNCTION CONNECTOR 19 (RIGHT SIDE OF DASH) JUNCTION CONNECTOR 22 (RIGHT SIDE OF DASH) JUNCTION CONNECTOR 31 (LEFT REAR OF VEHICLE, BEHIND BUMPER) JUNCTION CONNECTOR 32 (LEFT REAR OF VEHICLE, BEHIND BUMPER) BP MPX OFF OFF LO HI ON+WASH ORG/ WIRE PNK PNK WIRE PNK WIRE PNK WRSW WIRE PNK/BLU WIRE PNK/GRN WIRE POWER WINDOW MASTER SWITCH REAR WIPER MOTOR (IN CENTER OF LIFTGATE) REAR WIPER/ WASHER SWITCH RED WIRE RED/BLK WIRE RED/BLU WIRE RR WASHER FUSE RR WIPER FUSE RWLM RWSM SKID CONTROL ECU, ACTUATOR (LEFT REAR OF ENGINE COMPT) SPEEDO- METER SUB BODY ECU (BELOW LEFT "D" PILLAR, BEHIND TRIM) VIO WIRE VIO/RED WIRE WASH WASHER MOTOR (AT RIGHT FRONT OF ENGINE COMPT, ON WASHER FLUID RESERVOIR) WHT WIRE WHT/BLK WIRE WHT/RED WIRE WIPER RELAY (BEHIND RIGHT SIDE OF DASH) WRIN WRLO
