Lexus GX J120 (2002-2009) off head tail light control switch rh Wiring diagram
This page shows the only wiring diagram for the component.off head tail light control switch rh, which is found in the car Lexus GX J120 (2002-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram off head tail light control switch rh (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 IG FRTR LR FRTL LL
2 FUSE
9 3 8 LTIN RTIN STIN
BLK WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU/BLK WIRE
BLU/YEL WIRE
BODY ECU
BQ (AT CENTER REAR OF HATCH)
BRN WIRE
COMBINATION METER
COMBINATION SWITCH
DRIVER SIDE J/B (BEHIND LOWER LEFT END OF DASH)
ECU-IG FUSE
EG (ON REAR OF LEFT CYLINDER HEAD)
EL ER
GRN WIRE
GRN/BLK WIRE
GRN/YEL WIRE
GRY WIRE
GRY/BLU WIRE
HAZARD SWITCH
HOT AT ALL TIMES
HOT IN ON OR START
J/B 2 (BEHIND CENTER OF DASH)
JUNCTION CONNECTOR 11 (LEFT END OF DASH)
JUNCTION CONNECTOR 14 (LEFT SIDE OF DASH)
JUNCTION CONNECTOR 17 (RIGHT SIDE OF DASH)
JUNCTION CONNECTOR 30 (LEFT REAR OF VEHICLE, BEHIND BUMPER)
JUNCTION CONNECTOR 32 (LEFT REAR OF VEHICLE, BEHIND BUMPER)
LEFT LICENSE PLATE LIGHT
LEFT REAR COMBINATION LIGHT TAIL LIGHT
LEFT TAIL IND
OFF HEAD TAIL LIGHT CONTROL SWITCH RH
RIGHT LICENSE PLATE LIGHT
RIGHT REAR COMBINATION LIGHT TURN SIGNAL LIGHT
RIGHT TAIL IND
STOP LIGHT
TAIL
TAIL FUSE
TAIL RELAY
TAIL- LIGHT
TOWING CONVERTER RELAY (ON LEFT SIDE OF CARGO AREA)
TURN SIGNAL FLASHER
TURN SIGNAL LIGHT
TURN SIGNAL SWITCH
VIO WIRE
WHT WIRE
WHT/BLK WIRE
WHT/GRN WIRE
Go to component -> Exterior lamps circuit (1 of 2) -> OFF HEAD TAIL LIGHT CONTROL SWITCH RH
