Lexus GX J120 (2002-2009) compt, on washer fluid reservoir) Wiring diagram
This page shows the only wiring diagram for the component.compt, on washer fluid reservoir), which is found in the car Lexus GX J120 (2002-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram compt, on washer fluid reservoir) (1 of 1)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
COMBINATION METER
COMBINATION SWITCH
COMPT, ON WASHER FLUID RESERVOIR)
DRIVER SIDE J/B (BEHIND LOWER LEFT END OF DASH)
EB (ON LEFT FRONT INNER FENDER)
FR WIP-WSH FUSE
FRONT WASHER SWITCH
FRONT WIPER MOTOR (AT LEFT REAR OF ENGINE COMPT)
FRONT WIPER SWITCH
GAUGE FUSE
GRN WIRE
HOT IN ON OR START
INT TIME
JUNCTION CONNECTOR 14 (LEFT SIDE OF DASH)
JUNCTION CONNECTOR 19 (RIGHT SIDE
JUNCTION CONNECTOR 2 (LEFT SIDE OF ENGINE COMPT)
OF DASH)
OFF
RED WIRE
RED/BLU WIRE
SHORT PIN 6, 7 (RIGHT SIDE OF DASH)
SOLID STATE
WASHER IND
WASHER LEVEL SENSOR (AT RIGHT FRONT OF ENGINE
WASHER MOTOR (AT RIGHT FRONT OF ENGINE COMPT)
WHT WIRE
WHT/BLK WIRE
YEL/RED WIRE
Go to component -> Front wiper/washer circuit, without rain sensor -> COMPT, ON WASHER FLUID RESERVOIR)
