Lexus GX J120 (2002-2009) bkup lp relay Wiring diagrams
This page contains all the electrical diagrams for the component. bkup lp relay, in which he is found in the car Lexus GX J120 (2002-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram bkup lp relay (1 of 2)
ACC CUT RELAY
BKUP LP RELAY
BLK WIRE
BLU WIRE
BQ (AT CENTER REAR OF HATCH)
DIODE (BACK-UP LIGHT) (BEHIND RIGHT SIDE OF DASH)
DRIVER SIDE J/B (BEHIND LOWER LEFT END OF DASH) 2 FUSE
ENGINE CONTROLS SYSTEM
ENGINE ROOM R/B (ON LEFT SIDE OF ENGINE COMPARTMENT)
FUSE
GRN WIRE
GRY WIRE
GRY/BLU WIRE
HOT IN ON OR ACC
HOT IN ON OR START
JUNCTION CONNECTOR
JUNCTION CONNECTOR 23 (LOWER RIGHT SIDE OF DASH)
JUNCTION CONNECTOR 33 (RIGHT REAR OF CARGO AREA)
LEFT BACK-UP LIGHT
PARK/NEUTRAL POSITION SWITCH (ON RIGHT SIDE OF TRANSMISSION)
PASSENGER SIDE R/B (AT RIGHT KICK PANEL)
RED WIRE
RED/BLK WIRE
RED/YEL WIRE
RIGHT BACK-UP LIGHT
TRAILER SOCKET
WHT WIRE
WHT/BLK WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> Back-up lamps circuit -> BKUP LP RELAY
