Lexus GX J120 (2002-2009) batt airv vpmp mpmp +bm mrel igsw fc Wiring diagram

ACCEL POSITION SENSOR (BEHIND LEFT SIDE OF DASH) ACCR VPA AIDI AIRP VCPA BATT AIRV VPMP MPMP +BM MREL IGSW FC BLK WIRE BLK/ORG WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE CAMSHAFT TIMING OIL CONTROL VALVE (LEFT) (ON FRONT OF LEFT CYLINDER HEAD) CAMSHAFT TIMING OIL CONTROL VALVE (RIGHT) (ON FRONT OF RIGHT CYLINDER HEAD) COMPUTER DATA LINES SYSTEM CRUISE CONTROL SYSTEM EB (ON LEFT FRONT INNER FENDER) EE (ON REAR OF RIGHT CYLINDER HEAD) EG (ON REAR J/C 24 OF LEFT (IN CYLINDER CENTER HEAD) CONSOLE) EG (ON REAR OF LEFT CYLINDER HEAD) ENGINE CONTROL MODULE (ECM) (BEHIND RIGHT SIDE OF DASH) FPR FUSE GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/GRN WIRE HOT IN ON OR ACC DRIVER SIDE J/B (BEHIND LOWER LEFT END OF DASH) HOT IN ON OR START INJ 1 INJ 2 INJ 3 INJ 4 INJ 5 INJ 6 J/C 10 (CENTER OF DASH) J/C 15 (RIGHT SIDE OF DASH) J/C 16 (RIGHT SIDE OF DASH) J/C 19 (RIGHT SIDE OF DASH) J/C 24 (IN CENTER CONSOLE) J/C 38 (BEHIND CENTER OF DASH) LT GRN WIRE LT GRN/BLK WIRE LT GRN/RED WIRE NCA WIRE NE- NE+ ORG/ WIRE P/N PNK WIRE PNK/BLU WIRE PPMP TC RB PL LL RL NL DL RED WIRE RED/BLK WIRE RED/BLU WIRE STA STSW TRANSMISSIONS SYSTEM VIO WIRE VVT SENSOR (LEFT) (TOP LEFT SIDE OF ENGINE) VVT SENSOR (RIGHT) J/C 20 (TOP RIGHT (RIGHT SIDE OF SIDE ENGINE) OF DASH) WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE YEL WIRE
