Lexus GX J120 (2002-2009) 14 20 26 11 15 ksw hr Wiring diagrams
This page contains all the electrical diagrams for the component. 14 20 26 11 15 ksw hr, in which he is found in the car Lexus GX J120 (2002-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram 14 20 26 11 15 ksw hr (1 of 2)
14 20 26 11 15 KSW HR
17 12 11 HRLY
23 20 19 15 ACT+
3 2 5 1 PRG RDA +B
3 4 7 12 11 24 23 PRG RDA BCTY RRCY RLCY PCTY DCTY
BACK DOOR COURTESY SWITCH (AT LEFT
BLK WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BODY ECU
BRN WIRE
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DOME FUSE
DOOR CONTROL RECEIVER (ON LEFT "D" PILLAR, BEHIND TRIM)
DR/LCK FUSE
DRIVER SIDE J/B (BEHIND LOWER LEFT END OF DASH)
ECU-B FUSE
ECU-IG FUSE
EG (ON REAR OF LEFT CYLINDER HEAD)
ENGINE ROOM R/B (ON LEFT SIDE OF ENGINE COMPARTMENT)
FUSE
GAUGE FUSE
GRN WIRE
GRN/ORG WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HEADLIGHTS SYSTEM
HEADLIGHTS SYSTEM COMPUTER DATA LINES SYSTEM
HOT AT ALL TIMES
HOT IN ON OR ACC
HOT IN ON OR START
IND
J/B 1 (BEHIND CENTER OF DASH)
J/B 2 (BEHIND CENTER OF DASH)
JUNCTION CONNECTOR
JUNCTION CONNECTOR 11 (LEFT END OF DASH)
JUNCTION CONNECTOR 13 (LEFT END OF DASH)
JUNCTION CONNECTOR 16 (RIGHT SIDE OF DASH)
JUNCTION CONNECTOR 23 (LOWER RIGHT SIDE OF DASH)
JUNCTION CONNECTOR 28 (AT RIGHT KICK PANEL)
JUNCTION CONNECTOR 30 (LEFT REAR OF VEHICLE, BEHIND BUMPER)
JUNCTION CONNECTOR 31 (LEFT REAR
JUNCTION CONNECTOR 32 (LEFT REAR OF VEHICLE, BEHIND BUMPER)
KSWO
LEFT FRONT DOOR COURTESY SWITCH (LOWER LEFT "B" PILLAR)
LEFT REAR DOOR COURTESY SWITCH (BOTTOM OF LEFT "C" PILLAR)
LSWP ACTD
LT GRN/BLK WIRE
OF VEHICLE, BEHIND BUMPER)
PNK/BLK WIRE
PNK/BLU WIRE
POWER DISTRIBUTION SYSTEM
REAR OF VEHICLE, BELOW TAILLIGHT)
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT DOOR LOCK CONTROL SWITCH
RIGHT FRONT DOOR COURTESY SWITCH (BOTTOM OF RIGHT "B" PILLAR)
RIGHT REAR DOOR COURTESY SWITCH (BOTTOM OF RIGHT "C" PILLAR)
SECURITY
SIG TRLY
VIO/WHT WIRE
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
Go to component -> Forced entry circuit (1 of 2) -> 14 20 26 11 15 KSW HR
