Lexus GX J120 (2002-2009) 12 11 8 1 9 stsw sta Wiring diagram
This page shows the only wiring diagram for the component.12 11 8 1 9 stsw sta, which is found in the car Lexus GX J120 (2002-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 12 11 8 1 9 stsw sta (1 of 1)
12 11 8 1 9 STSW STA
4 5 17 20 28 19 21 7 6 M- M+
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRN WIRE
CONTROL MOTOR, THROTTLE POSITION SENSOR (ON THROTTLE BODY)
DRIVER SIDE J/B (BEHIND FUSE LOWER LEFT END OF DASH)
EB (ON LEFT FRONT INNER FENDER)
EE (ON REAR OF RIGHT CYLINDER HEAD)
EG (ON REAR OF LEFT CYLINDER HEAD)
ELECTRONICALLY CONTROLLED TRANSMISSION SOLENOID (ON TRANSMISSION)
ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH)
ENGINE CONTROLS SYSTEM
ENGINE COOLANT TEMPERATURE SENSOR (ON RIGHT FRONT OF ENGINE)
GRN WIRE
GRN/BLK WIRE
GRY WIRE
HOT IN
J/C 10 (CENTER OF DASH)
J/C 26 (CENTER OF DASH)
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
NCA WIRE
NT+ NT- NSW/STAR
O/T
ORG/ WIRE
PNK/BLU WIRE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
SLT-
SLT- SLT+ SR
SLU+
SLU- SLU+
STARTING/ CHARGING SYSTEM
THROTTLE
VIO WIRE
WHT WIRE
WHT/ BLK WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> A/t circuit (3 of 3) -> 12 11 8 1 9 STSW STA
