Car Wiring Diagrams for Heated seats circuit for Lexus GS IV facelift (2015-2020)

A/C AMPLIFIER ASSEMBLY ACC FUSE BLK WIRE BLU WIRE COMPUTER DATA LINES SYSTEM CONTROL ENGINE ROOM R/B 1 ASSEMBLY GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ LEFT REAR SEAT BACK HEATER ASSEMBLY LEFT REAR SEAT HEATER ASSEMBLY LEFT SEAT HEATER LT GRN WIRE LUGGAGE ROOM J/B ASSEMBLY MPX-B FUSE PNK RLIN WIRE PNK WIRE REAR CONTROL SWITCH RED WIRE RELAY 1 ENERGIZED RH ACC RELAY RIGHT COWL SIDE J/B RIGHT REAR SEAT BACK HEATER ASSEMBLY RIGHT REAR SEAT HEATER ASSEMBLY RIGHT SEAT HEATER RR ECU-IG FUSE RR S/HTR FUSE SEAT HEATER SWITCH SHDE SHPE TFAL TFAR VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE
