Lexus GS IV facelift (2015-2020) wht/blk Wiring diagrams
This page contains all the electrical diagrams for the component. wht/blk, in which he is found in the car Lexus GS IV facelift (2015-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram wht/blk (211 of 240)
ASC
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
ENGINE ROOM R/B 1 ASSEMBLY
GRN WIRE
HOT AT ALL TIMES
IND
INTEGRATION CONTROL, PANEL ASSEMBLY
LEFT COWL SIDE J/B
LH ECU-IG FUSE
LT GRN WIRE
MPX-B FUSE
PNK WIRE
RED WIRE
RELAY 1 ENERGIZED
RH-IG FUSE
RIGHT COWL SIDE J/B
SPEAKER W/ BOX ASSEMBLY 1
SPEAKER W/ BOX ASSEMBLY 2
SPO-
STEREO COMPONENT EQUALIZER ASSEMBLY
VIO WIRE
WHT WIRE
WHT/BLK WIRE
Go to component: -> Active sound control circuit -> WHT/BLK WIRE
Wiring diagram wht/blk (212 of 240)
A/C AMPLIFIER ASSEMBLY
ABSORBER CONTROL ECU
ACCESSORY METER ASSEMBLY
BLK WIRE
BLOWER MOTOR W/ FAN SUB-ASSEMBLY
BRN WIRE
CAN JUNCTION TERMINAL 1
CERTIFICATION ECU
CLOCK ASSEMBLY
DCM (TELEMATICS TRANSCEIVER)
ENGINE ROOM R/B 1 ASSEMBLY
FR PWR OUTLET RELAY
GLOVE BOX LIGHT ASSEMBLY
ID CODE BOX
IGNITION COIL ASSEMBLY 7
IGNITION COIL ASSEMBLY 8
LUGGAGE DOOR OPENING CANCEL SWITCH ASSEMBLY
MAP LIGHT ASSEMBLY
MULTI-DISPLAY
NETWORK GATEWAY ECU
OCCUPANT DETECTION ECU
OPTION CONNECTOR (GLASS BREAKAGE SENSOR ECU)
POWER STEERING ECU ASSEMBLY
RH ACC RELAY
RIGHT COWL SIDE J/B
RIGHT END OF DASH)
RR PWR OUTLET RELAY
ST RELAY
STEREO COMPONENT EQUALIZER ASSEMBLY
TIRE PRESSURE MONITOR INITIATOR DRIVER
W/ NAVIGATION
W/O NAVIGATION
WHT/BLK WIRE
WIRING HARNESS CONDENSER ASSEMBLY 1
YAW RATE SENSOR 2
Go to component: -> Ground distribution circuit (2 of 8) -> WHT/BLK WIRE
Wiring diagram wht/blk (213 of 240)
A/F RELAY
BLK WIRE
BRAKE ACTUATOR ASSEMBLY
BRAKE FLUID LEVEL WARNING SWITCH (BRAKE MASTER CYLINDER RESERVOIR ASSEMBLY)
BRN WIRE
COMPRESSOR W/ PULLEY ASSEMBLY
DIRECT FUEL INJECTOR ASSEMBLY 1 SHIELD
DIRECT FUEL INJECTOR ASSEMBLY 2 SHIELD
DIRECT FUEL INJECTOR ASSEMBLY 3 SHIELD
DIRECT FUEL INJECTOR ASSEMBLY 4 SHIELD
DIRECT FUEL INJECTOR ASSEMBLY 5 SHIELD
DIRECT FUEL INJECTOR ASSEMBLY 6 SHIELD
DIRECT FUEL INJECTOR ASSEMBLY 7 SHIELD
DIRECT FUEL INJECTOR ASSEMBLY 8 SHIELD
EFI MAIN 2 RELAY
EFI MAIN RELAY
ENGINE ROOM R/B 2 ASSEMBLY
ENGINE ROOM R/B 3 ASSEMBLY
FAN 1 RELAY
FAN 2 RELAY
LEVEL WARNING SWITCH ASSEMBLY
SHIELD
TORQUE VECTORING DIFFERENTIAL ECU ASSEMBLY
TRANSMISSION CONTROL ECU ASSEMBLY
WHT/BLK WIRE
WIRELESS DOOR LOCK BUZZER
Go to component: -> Ground distribution circuit (3 of 8) -> WHT/BLK WIRE
Wiring diagram wht/blk (214 of 240)
AIR FUEL RATIO SENSOR (BANK 1 SENSOR 1) SHIELD
AIR FUEL RATIO SENSOR (BANK 2 SENSOR 1) SHIELD
BRN WIRE
CANISTER PUMP MODULE (LEAK DETECTION PUMP SUB-ASSEMBLY)
CRUISE CONTROL SWITCH WIRE
DATA LINK CONNECTOR 3
ENGINE OIL LEVEL SENSOR
IGNITION COIL ASSEMBLY 1
IGNITION COIL ASSEMBLY 2
IGNITION COIL ASSEMBLY 3
IGNITION COIL ASSEMBLY 4
IGNITION COIL ASSEMBLY 5
IGNITION COIL ASSEMBLY 6
INJECTOR DRIVER 1 SHIELD
INJECTOR DRIVER 2 SHIELD
LEFT CAMSHAFT TIMING CONTROL W/ EDU MOTOR ASSEMBLY
LEFT FUEL PUMP W/ SEAL SUB-ASSEMBLY SHIELD
REAR OXYGEN SENSOR (BANK 1 SENSOR 2) SHIELD
REAR OXYGEN SENSOR 2 (BANK 2 SENSOR 2) SHIELD
RIGHT CAMSHAFT TIMING CONTROL W/ EDU MOTOR ASSEMBLY
RIGHT FUEL PUMP W/ SEAL SUB- ASSEMBLY SHIELD
SHIELD
SPIRAL CABLE SUB-ASSEMBLY
STEERING COLUMN)
STEERING PAD SWITCH ASSEMBLY
TRANSMISSION CONTROL ECU ASSEMBLY
TRANSMISSION CONTROL SWITCH (TRANSMISSION FLOOR SHIFT ASSEMBLY)
W/O DYNAMIC RADAR CRUISE CONTROL
WHT/BLK WIRE
Go to component: -> Ground distribution circuit (4 of 8) -> WHT/BLK WIRE
Wiring diagram wht/blk (215 of 240)
BACKUP LP RELAY
BATTERY
BLK WIRE
BLK/DK GRN WIRE
CAN JUNCTION TERMINAL 2
CENTER STOP LIGHT ASSEMBLY
FUEL PUMP CONTROL ECU
LEFT BLIND SPOT MONITOR SENSOR
LEFT FRONT MULTIPLEX NETWORK DOOR ECU
LEFT FRONT SEAT HEATER CONTROL SUB-ASSEMBLY
LEFT FRONT SEAT INNER BELT ASSEMBLY
LEFT POSITION CONTROL ECU ASSEMBLY
LEFT REAR COMBINATION LIGHT ASSEMBLY
LEFT REAR DOOR LOCK ASSEMBLY
LEFT REAR DOOR OUTSIDE HANDLE ASSEMBLY
LEFT REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY
LEFT REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY
LEFT REAR SEAT INNER W/ CENTER ASSEMBLY
LEFT SEAT CUSHION CLIMATE CONTROL BLOWER ASSEMBLY
LUGGAGE CLOSER MOTOR ASSEMBLY
LUGGAGE ROOM J/B ASSEMBLY
MULTIPLEX NETWORK DOOR ECU
NCA WIRE
PARKING BRAKE ECU ASSEMBLY
REAR OF ENGINE COMPT)
RIGHT FRONT MULTIPLEX NETWORK DOOR ECU
RIGHT REAR COMBINATION LIGHT ASSEMBLY
SECURITY HORN RELAY
W/ POWER TRUNK OPENER, CLOSER
WHT WIRE
WHT/BLK WIRE
Go to component: -> Ground distribution circuit (5 of 8) -> WHT/BLK WIRE
Wiring diagram wht/blk (216 of 240)
AIR BAG ECU ASSEMBLY
ALL DOOR LOCK RELAY
BRN WIRE
CLEARANCE WARNING ECU ASSEMBLY
COMBINATION METER ASSEMBLY
D DOOR UNLOCK RELAY
DATA LINK CONNECTOR 3
DRIVING SUPPORT ECU ASSEMBLY
FORWARD RECOGNITION CAMERA
FUEL OPEN RELAY
HEADLIGHT DIMMER SWITCH ASSEMBLY
HEADUP DISPLAY (COMBINATION METER MIRROR ECU)
INTEGRATION CONTROL, PANEL ASSEMBLY
L/D DOOR UNLOCK RELAY
LEFT COWL SIDE J/B
LEFT VISOR ASSEMBLY
LUGGAGE COMPARTMENT DOOR OPENING SWITCH ASSEMBLY
MAIN BODY ECU
MAP LIGHT ASSEMBLY
MULTIPLEX TILT, TELESCOPIC ECU
OPTION CONNECTOR (REMOTE ENGINE STARTER)
POWER OUTLET SOCKET ASSEMBLY
RIGHT VISOR ASSEMBLY
SHIFT LOCK CONTROL ECU (TRANSMISSION FLOOR SHIFT ASSEMBLY)
SLIDING ROOF CONTROL ECU (SLIDING ROOF DRIVE GEAR SUB-ASSEMBLY)
SPIRAL CABLE SUB-ASSEMBLY
STEERING COLUMN)
STEERING LOCK ACTUATOR ASSEMBLY
STEERING PAD SWITCH ASSEMBLY
STEERING SENSOR
STEERING WHEEL HEATER CONTROL ASSEMBLY
TILT STEERING GEAR ASSEMBLY W/ MOTOR
TRIP SWITCH
WHT WIRE
WHT/BLK WIRE
WINDSHIELD WIPER SWITCH ASSEMBLY
Go to component: -> Ground distribution circuit (6 of 8) -> WHT/BLK WIRE
Wiring diagram wht/blk (217 of 240)
BLK WIRE
BLK/DK GRN WIRE
BRN WIRE
CONSOLE BOX ILLUMINATION LIGHT ASSEMBLY
DOOR CONTROL SWITCH
DOOR UNLOCK SWITCH SUB-ASSEMBLY
FROM GROUND TB (DIAGRAM 7 OF 8)
LEFT FRONT MULTIPLEX NETWORK DOOR ECU
LEFT LICENSE PLATE LIGHT ASSEMBLY
LEFT REAR LIGHT ASSEMBLY
LUGGAGE ELECTRICAL KEY SWITCH
REAR CONTROL SWITCH
REAR WINDOW DEFOGGER (BACK WINDOW GLASS)
RIGHT BLIND SPOT MONITOR SENSOR
RIGHT FRONT SEAT INNER BELT ASSEMBLY
RIGHT OCCUPANT DETECTION SENSOR (RIGHT FRONT SEAT CUSHION W/ COVER PAD)
RIGHT REAR LIGHT ASSEMBLY
RIGHT REAR SEAT INNER W/ CENTER ASSEMBLY
RIGHT REAR SPEED SENSOR
STEREO COMPONENT AMPLIFIER ASSEMBLY
THEFT WARNING SIREN ASSEMBLY
W/ POWER TRUNK OPENER, CLOSER
WHT/BLK WIRE
Go to component: -> Ground distribution circuit (8 of 8) -> WHT/BLK WIRE
Wiring diagram wht/blk (218 of 240)
A/C AMPLIFIER ASSEMBLY
ACC FUSE
AIR
AMPLIFIER ANTENNA ASSEMBLY
ARON
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
DOOR LOCKS, ANTI-THEFT SYSTEMS
GPS ANTENNA
GRN WIRE
GRY WIRE
GVIF
HOT AT ALL TIMES
KD (UNDER CENTER CONSOLE)
LT BLU WIRE
LT GRN WIRE
MACC
MIN
MULTIMEDIA FUSE
NCA WIRE
PASSENGER AIRBAG ON/OFF INDICATOR
PNK WIRE
POWER WINDOWS SYSTEM
RADIO RECEIVER ASSEMBLY
REAR A/C SWITCH REAR CONTROL SWITCH
RED WIRE
RELAY 1 ENERGIZED
RH ECU-IG FUSE
RIGHT ACC RELAY
RIGHT COWL SIDE J/B
RLIN
SDARS ANTENNA
SEUC
SGND
SHIELD
SUPPLEMENTAL RESTRAINTS SYSTEM
SWG
VIO WIRE
VMTF
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component: -> Radio circuit (1 of 6) -> WHT/BLK WIRE
Wiring diagram wht/blk (219 of 240)
ACCD
BLK WIRE
BLU WIRE
CA+
CERTIFICATION ECU (RIGHT END OF DASH)
CGND
ENGINE ROOM R/B 1 ASSEMBLY
ENGINE ROOM R/B 2 ASSEMBLY
GAUGE FUSE
GRN WIRE
GRY WIRE
GVIF
HOT AT ALL TIMES
ILL
LEFT COWL SIDE J/B
LH-IG FUSE
LT BLU WIRE
LT GRN WIRE
LUGGAGE ROOM J/B ASSEMBLY
MPX-B FUSE
MULTI-DISPLAY (W/O NAVIGATION) ACCESSORY METER ASSEMBLY (W/ NAVIGATION)
PNK WIRE
RED WIRE
RELAY 1 ENERGIZED
RELAY ENERGIZED
REV
RR ECU-IG FUSE
SHIELD
VMTI
W/O NAVIGATION W/ NAVIGATION
WHT WIRE
WHT/BLK WIRE
WUI
WUO
YEL WIRE
Go to component: -> Radio circuit (2 of 6) -> WHT/BLK WIRE
Wiring diagram wht/blk (220 of 240)
BLK WIRE
BLU WIRE
BRN WIRE
CB+
CGND
COMPUTER DATA LINES SYSTEM
CV+
DIODE (A/T SHIFT)
EAU
GRN WIRE
GRY WIRE
LEFT STEERING PAD SWITCH STEERING PAD SWITCH ASSEMBLY
LT BLU WIRE
LT GRN WIRE
MI+
MO-
MODE
OFF HOOK
ON HOOK
PARK/NEUTRAL POSITION SWITCH ASSEMBLY
PNK WIRE
REAR TELEVISION CAMERA ASSEMBLY
RED WIRE
REMOTE OPERATION SWITCH
SEEK
SHIELD
SPIRAL CABLE SUB-ASSEMBLY
STEERING COLUMN)
VIO WIRE
VOICE
VOLUME-
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component: -> Radio circuit (3 of 6) -> WHT/BLK WIRE
