Lexus GS IV facelift (2015-2020) parking light switch assembly Wiring diagrams
This page contains all the electrical diagrams for the component. parking light switch assembly, in which he is found in the car Lexus GS IV facelift (2015-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram parking light switch assembly (1 of 6)
AUTO
BLK WIRE
BLU WIRE
CAN I/F
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
ECU-B 3 FUSE
ELECTRIC PARKING BRAKE SWITCH ASSEMBLY
ENGINE ROOM R/B 1 ASSEMBLY
ENGINE ROOM R/B 2 ASSEMBLY
EPB
EPB FUSE
GAUGE FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
IND IND
LED DRIVER
LEFT COWL SIDE J/B
LH ECU-IG FUSE
LOCK
LPA
LUGGAGE ROOM J/B ASSEMBLY
ORG/ WIRE
PARKING BRAKE ACTUATOR ASSEMBLY W/ BRACKET
PARKING BRAKE ECU ASSEMBLY
PARKING LIGHT SWITCH ASSEMBLY
PNK WIRE
RED WIRE
RELAY 1 ENERGIZED
RELAY ENERGIZED
RELEASE
RR ECU-IG FUSE
SHIELD
TELLTALES
TGND
TSEN
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Electric parking brake circuit -> PARKING LIGHT SWITCH ASSEMBLY
Wiring diagram parking light switch assembly (2 of 6)
A/T SHIFT POSITION INDICATOR (SHIFTING HOLE FRAME SUB-ASSEMBLY)
AIR BAG ECU ASSEMBLY
BRAKE PEDAL LOAD SENSING SWITCH (BRAKE PEDAL SUPPORT ASSEMBLY)
BRN WIRE
COMBINATION METER ASSEMBLY
COMBINATION SWITCH ASSEMBLY
ELECTRIC PARKING BRAKE SWITCH ASSEMBLY
ENGINE ROOM J/B 2 ASSEMBLY
ENGINE ROOM R/B 3 ASSEMBLY
FRONT WIPER DEICER (WINDSHIELD GLASS)
INTEGRATION RELAY
KICK DOWN SWITCH ASSEMBLY
LEFT VVT RELAY
LT GRN WIRE
PARKING LIGHT SWITCH ASSEMBLY
RADIO RECEIVER ASSEMBLY
REAR SUNSHADE SWITCH ASSEMBLY
REFRESHING SEAT SWITCH
REMOTE OPERATION SWITCH
RIGHT VVT RELAY
SPIRAL CABLE SUB-ASSEMBLY
STEERING COLUMN)
STEERING PAD SWITCH ASSEMBLY
STOP LIGHT SWITCH ASSEMBLY
W/ CLIMATE CONTROL SEAT
WHT/BLK WIRE
WINDSHIELD WIPER MOTOR ASSEMBLY
YAW RATE SENSOR 1
Go to component -> Ground distribution circuit (1 of 8) -> PARKING LIGHT SWITCH ASSEMBLY
Wiring diagram parking light switch assembly (3 of 6)
AIR BAG SENSOR ASSEMBLY
BLK WIRE
BRN WIRE
COMBINATION METER ASSEMBLY
COMBINATION SWITCH ASSEMBLY
DATA LINK CONNECTOR 3
DRIVING SUPPORT ECU ASSEMBLY
ELECTRIC PARKING BRAKE SWITCH ASSEMBLY
FROM SPIRAL CABLE SUB-ASSEMBLY (DIAGRAM 3 OF 7)
MAP LIGHT ASSEMBLY
MULTI-MEDIA MODULE RECEIVER ASSEMBLY
MULTIPLEX TILT, TELESCOPIC ECU
PARKING LIGHT SWITCH ASSEMBLY
POWER MANAGEMENT CONTROL ECU
POWER OUTLET SOCKET ASSEMBLY
REAR SUNSHADE SWITCH ASSEMBLY
REFRESHING SEAT SWITCH
REMOTE OPERATION SWITCH
SATELLITE SWITCH SET
SLIDING ROOF CONTROL ECU (SLIDING ROOF DRIVE GEAR SUB-ASSEMBLY)
SPIRAL CABLE SUB-ASSEMBLY
STEERING LOCK ACTUATOR ASSEMBLY
TRANSMISSION CONTROL SWITCH (TRANSMISSION FLOOR SHIFT ASSEMBLY)
WHT WIRE
WHT/BLK WIRE
YAW RATE SENSOR
Go to component -> Ground distribution circuit (4 of 7) -> PARKING LIGHT SWITCH ASSEMBLY
Wiring diagram parking light switch assembly (4 of 6)
A/C AMPLIFIER ASSEMBLY
A/T SHIFT POSITION INDICATOR (SHIFTING HOLE FRAME SUB-ASSEMBLY)
ABSORBER CONTROL ECU
ACCESSORY METER ASSEMBLY
AIR BAG SENSOR ASSEMBLY
BLK WIRE
CANISTER PUMP MODULE
CERTIFICATION ECU
CLOCK ASSEMBLY
COMBINATION METER ASSEMBLY
COMBINATION SWITCH ASSEMBLY
DCM (TELEMATICS TRANSCEIVER)
ELECTRIC PARKING BRAKE SWITCH ASSEMBLY
FR PWR OUTLET RELAY
FRONT STEERING CONTROL ECU
GLOVE BOX LIGHT (INTERIOR ILLUMINATION LIGHT SUB ASSEMBLY)
ID CODE BOX
ION GENERATOR SUB- ASSEMBLY 1
JUNCTION TERMINAL
LUGGAGE DOOR OPENING CANCEL SWITCH ASSEMBLY
MAP LIGHT ASSEMBLY
MULTI-DISPLAY
MULTI-MEDIA MODULE RECEIVER ASSEMBLY
NETWORK GATEWAY ECU
PARKING LIGHT SWITCH ASSEMBLY
QUICK HEATER ASSEMBLY
REAR SUNSHADE SWITCH ASSEMBLY
REFRESHING SEAT SWITCH
REMOTE OPERATION SWITCH
RH ACC RELAY
RIGHT FRONT SEAT INNER BELT ASSEMBLY
RR PWR OUTLET RELAY
TIRE PRESSURE MONITOR INITIATOR DRIVER
TRANSMISSION CONTROL SWITCH (TRANSMISSION FLOOR SHIFT ASSEMBLY)
W/ NAVIGATION
W/O NAVIGATION
WHT WIRE
WHT/BLK WIRE
YAW RATE SENSOR
Go to component -> Ground distribution circuit (5 of 6) -> PARKING LIGHT SWITCH ASSEMBLY
Wiring diagram parking light switch assembly (5 of 6)
ACCESSORY METER ASSEMBLY
BLK WIRE
CLOCK ASSEMBLY
DOME
ELECTRIC PARKING BRAKE SWITCH ASSEMBLY
GRN WIRE
HEADUP DISPLAY SWITCH ASSEMBLY
ILL
ILLB
INSTRUMENT PANEL REGISTER ASSEMBLY 3
INTEGRATION CONTROL, PANEL ASSEMBLY
LIGHT SWITCH IND
LILL
LUGGAGE COMPARTMENT DOOR OPENING SWITCH ASSEMBLY
MAP
MAP LIGHT ASSEMBLY
PARKING LIGHT SWITCH ASSEMBLY
PNK WIRE
RIGHT COWL SIDE J/B
RLMP
ROOF SWITCH IND
SLIDING
SPOT LIGHT ASSEMBLY
TRIP SWITCH
VIO WIRE
W/ NAVIGATION
W/O NAVIGATION
WHT WIRE
WHT/BLK WIRE
Go to component -> Instrument illumination circuit (3 of 4) -> PARKING LIGHT SWITCH ASSEMBLY
Wiring diagram parking light switch assembly (6 of 6)
AUTO
BLK WIRE
BLU WIRE
CAN I/F
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
ECU-B 3 FUSE
ELECTRIC PARKING BRAKE SWITCH ASSEMBLY
ENGINE ROOM R/B 1 ASSEMBLY
EPB
EPB FUSE
GAUGE FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/
IND IND
LED DRIVER
LEFT COWL SIDE J/B
LH ECU-IG FUSE
LOCK
LPA
LUGGAGE ROOM J/B 1 ASSEMBLY
MPX-B FUSE
PARKING BRAKE ACTUATOR W/ BRACKET ASSEMBLY
PARKING BRAKE ECU ASSEMBLY
PARKING LIGHT SWITCH ASSEMBLY
PNK WIRE
RED WIRE
RELAY 1 ENERGIZED
RELEASE
RR ECU-IG FUSE
SHIELD
SHIELD SG
TELLTALES
TGND
TSEN
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Park brake release circuit -> PARKING LIGHT SWITCH ASSEMBLY
