Lexus GS IV facelift (2015-2020) oil pressure switching valve assembly Wiring diagram
This page shows the only wiring diagram for the component.oil pressure switching valve assembly, which is found in the car Lexus GS IV facelift (2015-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram oil pressure switching valve assembly (1 of 1)
ABV
BLK WIRE
BLU WIRE
BRN WIRE
CRANK POSITION SENSOR
ECM (LEFT SIDE OF ENGINE COMPT)
EOJV
ETHA
ETHE
ETHO
GRN WIRE
INTAKE MASS AIR FLOW METER SUB-ASSEMBLY
LT BLU WIRE
LT GRN WIRE
NE+
NTB
NTO
OIL PRESSURE SWITCHING VALVE ASSEMBLY
PEO
PNK WIRE
PURGE VSV
RED WIRE
THA
THEO
VACUUM SWITCHING VALVE ASSEMBLY 2
VIO WIRE
VVE-
VVI+
VVT SENSOR (EXHAUST SIDE)
VVT SENSOR (INTAKE SIDE)
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 2.0l turbo (6 of 9) -> OIL PRESSURE SWITCHING VALVE ASSEMBLY
