Lexus GS IV facelift (2015-2020) mirror adjust switch ind Wiring diagram
This page shows the only wiring diagram for the component.mirror adjust switch ind, which is found in the car Lexus GS IV facelift (2015-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram mirror adjust switch ind (1 of 1)
BACK SONAR OR CLEARANCE SONAR SWITCH ASSEMBLY
BLK WIRE
CONSOLE BOX ILLUMINATION LIGHT ASSEMBLY
DOOR LOCK
ENGINE ROOM J/B 2 ASSEMBLY
GNDA (-)
GRN WIRE
INSTRUMENT PANEL REGISTER ASSEMBLY 1
INTEGRATION RELAY
LT GRN WIRE
MIRROR ADJUST SWITCH IND
MIRROR R/L
MIRROR RETRACT
PNK WIRE
PNL
PNLS
POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY
RADIO RECEIVER ASSEMBLY
REAR CONTROL SWITCH
RED WIRE
REFRESHING SEAT SWITCH
RIGHT FRONT POWER WINDOW REGULATOR SWITCH ASSEMBLY
SELECT SWITCH IND
SWITCH IND
TAIL
UNLOCK SWITCH IND
VIO WIRE
WHT WIRE
WHT/BLK WIRE
WINDOW LOCK
Go to component: -> Instrument illumination circuit (2 of 4) -> MIRROR ADJUST SWITCH IND
