Lexus GS IV facelift (2015-2020) left fuel pump w/ seal sub-assembly Wiring diagram
This page shows the only wiring diagram for the component.left fuel pump w/ seal sub-assembly, which is found in the car Lexus GS IV facelift (2015-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left fuel pump w/ seal sub-assembly (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
DIRECT FUEL INJECTOR ASSEMBLY 1, 7
DIRECT FUEL INJECTOR ASSEMBLY 4, 6
EX+
FP-
FPD +
GRN WIRE
GRY WIRE
INTAKE MASS AIR FLOW METER SUB-ASSEMBLY
LEFT FUEL PUMP W/ SEAL SUB-ASSEMBLY
LT GRN WIRE
ORG/ WIRE
PARK/NEUTRAL POSITION SWITCH ASSEMBLY (RIGHT SIDE OF TRANSMISSION)
PNK WIRE
RED WIRE
SHIELD
STARTING/ CHARGING SYSTEM
THA
VIO WIRE
VVL+
VVR+
VVT SENSOR (BANK 1 EXHAUST SIDE)
VVT SENSOR (BANK 1 INTAKE SIDE)
VVT SENSOR (BANK 2 INTAKE SIDE)
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 5.0l (7 of 11) -> LEFT FUEL PUMP W/ SEAL SUB-ASSEMBLY
