Lexus GS IV facelift (2015-2020) left front acceleration sensor Wiring diagram
This page shows the only wiring diagram for the component.left front acceleration sensor, which is found in the car Lexus GS IV facelift (2015-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front acceleration sensor (1 of 1)
ABSORBER CONTROL ECU
AVS FUSE
BLK WIRE
BLU WIRE
BRN WIRE
CAN I/F
COMBINATION METER ASSEMBLY
COMBINATION SWITCH ASSEMBLY
COMPUTER DATA LINES SYSTEM
DUMY
ENGINE ROOM R/B 1 ASSEMBLY
ENGINE ROOM R/B 2 ASSEMBLY
FAL+
FAR-
GAUGE FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/
IGB
LED
LEFT FRONT ACCELERATION SENSOR
LEFT FRONT SHOCK ABSORBER ASSEMBLY
LEFT REAR SHOCK ABSORBER ASSEMBLY
LT GRN WIRE
MPX-B FUSE
NORMAL
PNK WIRE
PWMS
RAL+
RAR+
RED WIRE
RELAY 2 ENERGIZED
RIGHT COWL SIDE J/B
RIGHT FRONT SHOCK ABSORBER ASSEMBLY
RIGHT REAR ACCELERATION SENSOR
RIGHT REAR SHOCK ABSORBER ASSEMBLY
SGB
SGFL
SGG
SGND
SGRR
SGV
SNOW
SNWI
SPCN
SPORT
TAN WIRE
TELLTALES
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component: -> Electronic suspension circuit -> LEFT FRONT ACCELERATION SENSOR
