Lexus GS IV facelift (2015-2020) fan relay 1 Wiring diagram
This page shows the only wiring diagram for the component.fan relay 1, which is found in the car Lexus GS IV facelift (2015-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fan relay 1 (1 of 1)
2.0L TURBO
4WD 2WD 3.5L 2.0L TURBO
A/C COMP RELAY
A/F RELAY
BLK WIRE
BLOWER MOTOR SUB ASSEMBLY W/ FAN
BRAKE ACTUATOR ASSEMBLY
BRAKE FLUID LEVEL WARNING SWITCH (BRAKE MASTER CYLINDER RESERVOIR ASSEMBLY)
BRAKE PEDAL LOAD SENSING SWITCH
BRN WIRE
COOLER COMPRESSOR ASSEMBLY
ENGINE ROOM J/B 2 ASSEMBLY
ENGINE ROOM R/B 1 ASSEMBLY
ENGINE ROOM R/B 2 ASSEMBLY
ENGINE ROOM R/B 3
FAN RELAY 1
FAN RELAY 2
FRONT STEERING CONTROL ECU
FRONT WIPER DEICER (WINDSHIELD GLASS)
HEADLIGHT CLEANER MOTOR, PUMP ASSEMBLY
INTEGRATION RELAY
KICK DOWN SWITCH ASSEMBLY
LEFT FRONT ABSORBER CONTROL ACTUATOR
LEVEL WARNING SWITCH ASSEMBLY
POWER STEERING ECU ASSEMBLY
RIGHT END OF DASH)
RIGHT FRONT ABSORBER CONTROL ACTUATOR
ST RELAY
STOP LIGHT SWITCH ASSEMBLY
VACUUM WARNING SWITCH ASSEMBLY
WHT/BLK WIRE
WINDSHIELD WIPER MOTOR ASSEMBLY
WIRELESS DOOR LOCK BUZZER
WIRING HARNESS CONDENSER ASSEMBLY 1
Go to component: -> Ground distribution circuit (1 of 6) -> FAN RELAY 1
