Lexus GS IV facelift (2015-2020) engine controls, shift interlock, door locks, anti-theft systems Wiring diagram
This page shows the only wiring diagram for the component.engine controls, shift interlock, door locks, anti-theft systems, which is found in the car Lexus GS IV facelift (2015-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram engine controls, shift interlock, door locks, anti-theft systems (1 of 1)
A/C FUSE
AIR CONDITIONING SYSTEM
ANTI-LOCK BRAKES SYSTEM
BLK WIRE
BLU WIRE
D/L 1 FUSE
D/L 2 FUSE
ENGINE CONTROLS CRUISE CONTROL, EXTERIOR LIGHTS SYSTEMS
ENGINE CONTROLS SYSTEM
ENGINE CONTROLS, SHIFT INTERLOCK, DOOR LOCKS, ANTI-THEFT SYSTEMS
F/L DOOR FUSE
FROM ENGINE ROOM J/B 1 ASSEMBLY (DIAGRAM 2 OF 7)
FROM FUSIBLE LINK BLOCK ASSEMBLY (DIAGRAM 1 OF 7)
GRN WIRE
HAZ FUSE
INSTRUMENT CLUSTER, EXTERIOR LIGHTS SYSTEMS
LH J/B-B FUSE
MAIN BODY ECU
MEMORY SYSTEMS
MEMORY, DOOR LOCKS, ANTI-THEFT, POWER WINDOWS SYSTEMS
MEMORY, POWER WINDOWS, DOOR LOCKS, ANTI-THEFT SYSTEMS
P/W-B FUSE
POWER CHANGE RELAY
POWER TOPS SYSTEM
POWER WINDOWS SYSTEM
R/L DOOR FUSE
RED WIRE
S/ROOF FUSE
SHIFT INTERLOCK, DOOR LOCKS, ANTI-THEFT SYSTEMS
STOP FUSE
STRG LOCK FUSE
TI, TE FUSE
VIO WIRE
WHT WIRE
YEL WIRE
Go to component: -> Power distribution circuit (7 of 7) -> ENGINE CONTROLS, SHIFT INTERLOCK, DOOR LOCKS, ANTI-THEFT SYSTEMS
