Lexus GS IV facelift (2015-2020) blind spot monitor buzzer wiring diagram
This page shows the only wiring diagram for the component.blind spot monitor buzzer, which is found in the car Lexus GS IV facelift (2015-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
blind spot monitor buzzer wiring diagram (1 of 1)
1) LEFT TURN 2) LEFT LANE CHANGE 3) NEUTRAL 4) RIGHT LANE CHANGE 5) RIGHT TURN
BLB
BLGD
BLIND SPOT MONITOR
BLIND SPOT MONITOR BUZZER
BLK WIRE
BLK/RED WIRE
BLU WIRE
BRB
BRGD
BSL+ BSMI
BSMI
BSR+
BZN
BZP
CAN I/F
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
ENGINE ROOM R/B 2 ASSEMBLY
GAUGE FUSE
GRN WIRE
GRY/RED WIRE
HEADLIGHT DIMMER SWITCH ASSEMBLY
LED DRIVER
LEFT BLIND SPOT MONITOR SENSOR
LEFT COWL SIDE J/B
LEFT FRONT MULTIPLEX NETWORK DOOR ECU
LEFT OUTER REAR VIEW MIRROR ASSEMBLY
LH-IG FUSE
LT GRN WIRE
LUGGAGE ROOM J/B ASSEMBLY
OMIL
OMIR
ORG/ WIRE
PNK BUZ WIRE
PNK WIRE
REAR CROSS TRAFFIC ALERT BUZZER
RED WIRE
RELAY 1 ENERGIZED
RELAY ENERGIZED
RIGHT BLIND SPOT MONITOR SENSOR
RIGHT FRONT MULTIPLEX NETWORK DOOR ECU
RIGHT OUTER REAR VIEW MIRROR ASSEMBLY
TELLTALES
TURN SWITCH
UB (LEFT SIDE OF LUGGAGE COMPT)
VIO WIRE
WHT WIRE
WHT/BLK WIRE
WINDSHIELD WIPER SWITCH ASSEMBLY
YEL WIRE
Go to component -> Blind spot monitoring circuit -> BLIND SPOT MONITOR BUZZER
