Lexus GS IV facelift (2015-2020) batt fan fuse Wiring diagrams

BATT FAN FUSE BATT FAN RELAY BATTERY VOLTAGE SENSOR BLK WIRE BLU WIRE BRN WIRE FCTL GRN WIRE HOT AT ALL TIMES LEFT "C" PILLAR) LEFT BATTERY COOLING BLOWER ASSEMBLY LT GRN WIRE LUGGAGE ROOM J/B 1 ASSEMBLY PNK WIRE POWER MANAGEMENT CONTROL ECU RED WIRE RIGHT BATTERY COOLING BLOWER ASSEMBLY RIGHT END OF DASH) VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE

AC INV (HV) FUSE AC INV (HV) RELAY AIR CONDITIONING, SEATS, SOUND, NAVIGATION SYSTEMS BACKUP FUSE BACKUP RELAY BATT FAN FUSE BATT FAN RELAY BLK WIRE BLU WIRE CRUISE CONTROL SYSTEM DCM FUSE ECU-B 3 FUSE ELECTRONIC POWER STEERING SYSTEM EPS-IG FUSE FR S/HTR FUSE FROM ENGINE ROOM J/B 1 ASSEMBLY (DIAGRAM 1 OF 7) FROM FUSIBLE LINK BLOCK ASSEMBLY (DIAGRAM 1 OF 7) FROM LEFT COWL SIDE J/B (DIAGRAM 4 OF 7) FROM PTL FUSE (DIAGRAM 6 OF 7) LEFT "C" PILLAR) LT GRN WIRE LUG CLOSER FUSE LUGGAGE ROOM J/B 1 ASSEMBLY NAVIGATION SYSTEM PASSIVE RESTRAINTS SYSTEM PNK WIRE PTL FUSE REAR POWER OUTLET SOCKET ASSEMBLY 2 RED WIRE RR ECU-IG FUSE RR J/B-B FUSE RR S/HTR FUSE SEATS SYSTEM SECURITY FUSE SECURITY HORN RELAY SHIFT INTERLOCK SYSTEM TO AC INV (HV) RELAY (DIAGRAM 6 OF 7) TRK OPN FUSE TRUNK, TAILGATE, FUEL DOORS SYSTEM VIO WIRE VOLTAGE INVERTER ASSEMBLY WARNING, DOOR LOCKS, ANTI-THEFT SYSTEMS WHT WIRE WHT/BLK WIRE

ACPB ACPE AIR CONDITIONING SYSTEM AMD BAT FAN RELAY BATT FAN FUSE BLK WIRE BLU WIRE BRN WIRE CBI CEI DC/DC FUSE DC/DC-S FUSE ENGINE ROOM J/B 1 ASSEMBLY GRN WIRE GRY WIRE HOT AT ALL TIMES HYBRID VEHICLE MOTOR HYBRID VEHICLE TRANSMISSION ASSEMBLY IDH IGCT ILKI INVERTER BUSBAR PLATE SUB-ASSEMBLY INVERTER W/ CONVERTER ASSEMBLY LEFT "C" PILLAR) LEFT BATTERY COOLING BLOWER ASSEMBLY LT BLU WIRE LT GRN WIRE LUGGAGE ROOM J/B 1 ASSEMBLY MCS MCSG MMT MMTG MRF MRFG MSN MSNG NODD OHG OHU OHV OHW OIGH OIL PUMP MOTOR CONTROLLER OIL PUMP W/ MOTOR ASSEMBLY OMT OMTG OPST ORG/ WIRE ORG/BLK WIRE ORG/WHT WIRE PNK WIRE RED WIRE REQ+ RIGHT BATTERY COOLING BLOWER ASSEMBLY SHIELD SIG VIO WIRE VLO WHT WIRE WHT/BLK WIRE YEL WIRE
