Lexus GS IV facelift (2015-2020) back sonar or clearance sonar switch assembly Wiring diagrams

This page contains all the electrical diagrams for the component. back sonar or clearance sonar switch assembly, in which he is found in the car Lexus GS IV facelift (2015-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram back sonar or clearance sonar switch assembly (1 of 2)

Wiring diagram back sonar or clearance sonar switch assembly for Lexus GS IV facelift (2015-2020)

Get access

BACK SONAR OR CLEARANCE SONAR SWITCH ASSEMBLY BLK WIRE CONSOLE BOX ILLUMINATION LIGHT ASSEMBLY DOOR LOCK ENGINE ROOM J/B 2 ASSEMBLY GNDA (-) GRN WIRE INSTRUMENT PANEL REGISTER ASSEMBLY 1 INTEGRATION RELAY LT GRN WIRE MIRROR ADJUST SWITCH IND MIRROR R/L MIRROR RETRACT PNK WIRE PNL PNLS POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY RADIO RECEIVER ASSEMBLY REAR CONTROL SWITCH RED WIRE REFRESHING SEAT SWITCH RIGHT FRONT POWER WINDOW REGULATOR SWITCH ASSEMBLY SELECT SWITCH IND SWITCH IND TAIL UNLOCK SWITCH IND VIO WIRE WHT WIRE WHT/BLK WIRE WINDOW LOCK

Go to component: -> Instrument illumination circuit (2 of 4) -> BACK SONAR OR CLEARANCE SONAR SWITCH ASSEMBLY

Wiring diagram back sonar or clearance sonar switch assembly (2 of 2)

Wiring diagram back sonar or clearance sonar switch assembly for Lexus GS IV facelift (2015-2020)

Get access

BACK SONAR OR CLEARANCE SONAR SWITCH ASSEMBLY BLK WIRE BLU WIRE CBZ CLEARANCE WARNING ECU ASSEMBLY COMPUTER DATA LINES SYSTEM GRN WIRE GRY WIRE LEFT COWL SIDE J/B LEFT FRONT ULTRASONIC SENSOR 1 LEFT REAR ULTRASONIC SENSOR 1 LH-IG FUSE LT BLU WIRE LT GRN WIRE PNK WIRE RED WIRE RELAY 1 ENERGIZED RIGHT FRONT ULTRASONIC SENSOR 1 RIGHT REAR CENTER ULTRASONIC SENSOR 1 RIGHT REAR ULTRASONIC SENSOR 1 VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE

Go to component: -> Rear sonar circuit (1 of 2) -> BACK SONAR OR CLEARANCE SONAR SWITCH ASSEMBLY
