Car Wiring Diagrams for Headlamps leveling circuit for Lexus GS IV (2011-2015)

31 32 ALTB IG 4 2 FRCY FLCY 6 29 RCTY HEAD BLK WIRE BLU WIRE CAN I/F COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM DATA LINK CONNECTOR 3 DISPLAY DRIVER ENGINE ROOM R/B 1 (LEFT SIDE OF ENGINE COMPT) GAUGE FUSE GRN WIRE HEADLIGHT DIMMER SWITCH ASSEMBLY HEADLIGHT LEVELING MOTOR HEADLIGHT SWIVEL ECU ASSEMBLY (BEHIND LEFT KICK PANEL) HOT AT ALL TIMES INIT INTERIOR LIGHTS SYSTEM INTERIOR LIGHTS SYSTEM LCTY LED DRIVER LEFT COWL SIDE J/B LH - LH E LH ECU-IG FUSE LH J/B-B FUSE LH-IG FUSE LHM+ LHT RHT LIGHT CONTROL SWITCH LT GRN WIRE LVL MAIN BODY ECU (LEFT END OF DASH) MPX-B FUSE OFF AUTO TAIL HEAD PNK RH+ CANH CANL IGS IG COMPUTER DATA LINES SYSTEM WIRE PNK WIRE RED WIRE RELAY ENERGIZED RH E RHM + RIGHT HEADLIGHT ASSEMBLY SBR SHRL PNK WIRE SGR SMGL SMGR TELLTALES VIO WIRE WHT WIRE WHT/BLK WIRE
