Lexus GS IV (2011-2015) Electronic power steering circuit

1 2 3 4 5 6 7 8 9 10 11 12 13 RZG SRZG RZV TRQV 1 2 3 4 8 5 6 ESS CANL CANH 28 29 CANH CANL 9 10 CSS- CSS+ BLK WIRE BLU WIRE BLU/WHT WIRE BRN WIRE COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM CPU CAN I/F ENGINE ROOM R/B 2 (LEFT SIDE EPS FUSE EPS RELAY EPS-B FUSE EPS-IG FUSE GAUGE FUSE GRN WIRE GRN/BLK WIRE GRN/WHT WIRE GRY WIRE HOT AT ALL TIMES HOT AT ALL TIMES ENGINE ROOM R/B 1 (RIGHT REAR OF ENGINE COMPT) MPX-B FUSE INCS INSN LED TELLTALES DRIVER LT BLU WIRE LT GRN WIRE LUGGAGE ROOM J/B 1 (LEFT SIDE OF LUGGAGE COMPT) NCA WIRE OF ENGINE COMPT) OUCS OUSN PGND PIG PNK WIRE POWER STEERING ECU (RIGHT REAR CORNER OF ENGINE COMPT) POWER STEERING MOTOR (LEFT FRONT OF ENGINE) RED WIRE RED/BLK WIRE RED/BLU WIRE RELAY ENERGIZED RELAY ENERGIZED LEFT COWL SIDE J/B (BEHIND LEFT END OF DASH) LH ECU-IG FUSE RLY RZCS RZG RZSN RZSN RZCS INSN INCS OUSN OUCS RZV STEERING SENSOR (ON STEERING COLUMN) VIO WIRE WHT WIRE WHT/BLK WIRE WINDSHIELD WIPER SWITCH ASSEMBLY YEL WIRE YEL/BLK WIRE

+B PGND 1 2 3 4 5 6 7 8 9 10 11 12 13 RZG SRZG RZV TRQV 1 2 3 4 5 6 7 8 ESS CANL CANH 10 11 12 13 14 15 16 17 18 PIG 9 10 CSS- CSS+ BLK WIRE BLU WIRE BLU/WHT WIRE BRN WIRE COMPUTER DATA LINES SYSTEM ENGINE ROOM R/B EPS-B FUSE (LEFT SIDE OF ENGINE COMPT) EPS-IG FUSE GRN WIRE GRN/BLK WIRE GRN/WHT WIRE GRY WIRE HOT AT ALL TIMES INCS INSN LEFT COWL SIDE J/B (LEFT END OF DASH) LH ECU-IG FUSE LT GRN WIRE LUGGAGE ROOM J/B 1 (LEFT SIDE OF LUGGAGE COMPT) MPX-B FUSE NCA WIRE OUCS OUSN PNK ASST IG WIRE PNK BAT WIRE PNK WIRE POWER STEERING ECU (RIGHT REAR CORNER OF ENGINE COMPT) POWER STEERING MOTOR (FRONT OF ENGINE COMPT) RED WIRE RED/BLK WIRE RED/BLU WIRE RELAY ENERGIZED RZCS RZG RZSN RZSN RZCS INSN INCS OUSN OUCS RZV STEERING SENSOR (ON STEERING COLUMN) WHT WIRE WHT/BLK WIRE WINDSHIELD WIPER SWITCH ASSEMBLY YEL WIRE YEL/BLK WIRE

1 2 3 4 5 CBP 28 29 CANH CANL BLK WIRE BLU WIRE BRN WIRE CAN I/F CBPE CEP CEPE COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT) EPS BLOCK FUSE (LEFT REAR OF LUGGAGE COMPT) FUSIBLE LINK GAUGE FUSE GRY WIRE HOT AT ALL TIMES HYBRID BATTERY JUNCTION BLOCK (TOP CENTER OF HV BATTERY ASSEMBLY) IG DDOK ASST LED DRIVER LEFT "C" PILLAR) PIG VGND PNK WIRE POWER MANAGEMENT CONTROL ECU (RIGHT END OF DASH) POWER STEERING CONVERTER ASSEMBLY (LEFT SIDE OF HV SUPPLY BATTERY ASSEMBLY) PSOK RED WIRE RELAY ENERGIZED SPEAKER TELLTALES VIO WIRE WHT WIRE WHT/BLK WIRE
