Cruise control circuit, with dynamic radar controls for Lexus GS IV (2011-2015)

BLK WIRE BLU WIRE BRN WIRE CCS HITP GND NAVIGATION SYSTEM COMPUTER DATA LINES SYSTEM DRIVING SUPPORT ECU ASSEMBLY (LEFT END OF DASH) EFI MAIN FUSE EFI MAIN RELAY 1 EFI MAIN RELAY 2 ENERGIZED LUGGAGE ROOM J/B 1 (LEFT SIDE OF FUSE LUGGAGE COMPT) ENGINE ROOM J/B 1 (LEFT SIDE OF ENGINE COMPT) F/PMP FUSE FUEL PUMP CONTROL ECU (LEFT SIDE OF LUGGAGE COMPT) FUSE GRN WIRE GRY WIRE HOT AT ALL TIMES IGB J/C LEFT COWL SIDE J/B (LEFT END OF DASH) LH ECU-IG FUSE LT GRN WIRE MILLIMETER WAVE RADAR SENSOR (CENTER OF FRONT FASCIA) NETWORK GATEWAY ECU (RIGHT CENTER OF DASH) PBSW SPSW PNK WIRE PRE-COLLISION SYSTEM CANCEL SWITCH RED WIRE RELAY ENERGIZED SGND STP+ VIO WIRE WHT WIRE WHT/BLK WIRE WIPER/ WASH CCHG WASHER SYSTEM WIPER/ WASHER WNKR WNKL SYSTEM YEL WIRE

12 25 2 46 1 CANP CANN +B MREL BATT 24 25 PNK WIRE 4 1 MREL ACCELERATOR PEDAL SENSOR (TOP OF ACCELERATOR PEDAL ASSEMBLY) BLK WIRE BLU WIRE BLU/BLK WIRE BRN WIRE COMPUTER DATA LINES SYSTEM CRUISE CONTROL MAIN SWITCH CRUISE CONTROL SWITCH ECM (ENGINE CONTROL MODULE) (LEFT SIDE OF ENGINE COMPT) GRN WIRE GRY WIRE HOT AT ALL TIMES J/C LEFT COWL SIDE J/B LT GRN WIRE M+ M- VCTA MODE NCA WIRE ON-OFF +RES -SET PNK WIRE POWER MANAGEMENT CONTROL ECU (RIGHT END OF DASH) RED WIRE RIGHT COWL SIDE PANEL J/B (RIGHT END OF DASH) RIGHT STEERING PAD SWITCH DISTANCE CONTROL SPIRAL CABLE SUB-ASSEMBLY (STEERING COLUMN) STEERING PAD SWITCH ASSEMBLY STOP FUSE STOP LIGHT SWITCH (BRAKE PEDAL BRACKET) THROTTLE BODY W/ MOTOR ASSEMBLY (TOP REAR OF ENGINE) VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE

1 11 10 16 15 GND RL+ RL- FR+ FR- PNK WIRE 16 15 11 10 FL+ FL- RR+ RR- 8 9 CANL CANH BLK WIRE BLU WIRE BRN WIRE CAN I/F COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM ENGINE ROOM R/B 1 (LEFT SIDE OF ENGINE COMPT) GAUGE FUSE GRN WIRE HOT AT ALL TIMES IGCT 5 FUSE IGCT IGCT 1 RELAY FUSE J/C LEFT FRONT SPEED SENSOR (LEFT FRONT WHEEL ASSEMBLY) LEFT REAR SPEED SENSOR (LEFT REAR WHEEL ASSEMBLY) LT GRN WIRE NCA WIRE PNK WIRE RED WIRE RELAY ENERGIZED RIGHT FRONT SPEED SENSOR (RIGHT FRONT WHEEL ASSEMBLY) SKID CONTROL ECU (LEFT REAR OF ENGINE COMPT) VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE
