Lexus GS IV (2011-2015) yel Wiring diagrams
This page contains all the electrical diagrams for the component. yel, in which he is found in the car Lexus GS IV (2011-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram yel (91 of 140)
11 12 CANN CANP
13 12 24 STP
2 1 PNK PNK +B WIRE
A/T SHIFT POSITION INDICATOR (SHIFTING HOLE FRAME SUB-ASSEMBLY)
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
ECM (ENGINE CONTROL MODULE) (LEFT SIDE OF ENGINE COMPT)
EFI FUSE
EFI- MAIN 1 RELAY
ENGINE ROOM J/B 2 (LEFT SIDE OF ENGINE COMPT)
GNDA (-)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES ENGINE ROOM R/B 1 (RIGHT REAR OF ENGINE COMPT)
INTEGRATION RELAY
LT BLU WIRE
NT- NT+
P/I-B 1 FUSE
PNK WIRE
RED WIRE
TRANSMISSION REVOLUTION SENSOR (COUNTER GEAR) (TRANSMISSION)
TRANSMISSION REVOLUTION SENSOR (TURBINE) (TRANSMISSION)
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component: -> A/t circuit (1 of 4) -> YEL WIRE
Wiring diagram yel (92 of 140)
BLK WIRE
BLU WIRE
DIODE (A/T SHIFT)
FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LT BLU WIRE
PADDLE SHIFT
PARK/NEUTRAL POSITION SWITCH (TRANSMISSION)
RED WIRE
RELAY ENERGIZED
RH ACC RELAY
RH ECU-IG FUSE
RIGHT COWL SIDE J/B (BEHIND RIGHT END OF DASH)
SFTD
SFTU
SHIFT DOWN
SHIFT UP
SPIRAL CABLE SUB-ASSEMBLY (STEERING COLUMN)
STARTING/ CHARGING SYSTEM
STEERING PAD SWITCH ASSEMBLY
SWITCH
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component: -> A/t circuit (2 of 4) -> YEL WIRE
Wiring diagram yel (93 of 140)
1 2 3 4 5 6 7 8 M- M+
10 6 5 VT TSEN
AUTO
AUTO IND
BLK WIRE
BLU WIRE
CAN I/F
CANH CANL 28 29 COMPUTER DATA LINES SYSTEM
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
ECU-B 3 FUSE
ELECTRIC PARKING BRAKE SWITCH
ENGINE ROOM R/B 1 (LEFT SIDE OF ENGINE COMPT)
EPB
GAUGE FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES FUSIBLE LINK EPB FUSE BLOCK (LEFT REAR OF LUGGAGE COMPT)
HOT AT ALL TIMES LUGGAGE ROOM J/B 1 (LEFT SIDE OF LUGGAGE COMPT)
HOT W/
IG AUTO PNK WIRE
ILL ILL
IND
LED DRIVER
LEFT COWL SIDE J/B (LEFT END OF DASH)
LH ECU-IG FUSE
LOCK
LPA TX +B
MPX-B FUSE
NCA WIRE
PARKING BRAKE ACTUATOR (LEFT REAR OF LUGGAGE COMPT)
PARKING BRAKE ECU (LEFT SIDE OF LUGGAGE COMPT)
PARKING LIGHT SWITCH ASSEMBLY
PNK WIRE
RED WIRE
RELEASE
RR ECU-IG FUSE
TELLTALES
TGND
TGND 1 2
VIO WIRE
VT TSEN
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component: -> Park brake release circuit -> YEL WIRE
Wiring diagram yel (94 of 140)
+B PGND
1 2 3 4 5 6 7 8 9 10 MOR- MOR+ MOL+ MOL-
1 2 3 4 5 6 7 8 CANH CANL
29 30 COMPUTER DATA LINES SYSTEM
5 39 PBSW COMPUTER DATA LINES SYSTEM 17 18 40
BLK WIRE
BLU WIRE
CAN I/F
CANH CANL 28 29 30
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DRIVING SUPPORT ECU (LEFT END OF DASH)
ENGINE ROOM R/B 1 (LEFT SIDE OF ENGINE COMPT)
GAUGE FUSE
GRN WIRE
HOT AT ALL TIMES LUGGAGE PSB FUSE ROOM J/B 1 (LEFT SIDE OF LUGGAGE COMPT)
HOT IN ON OR START RIGHT COWL COWL SIDE J/B RH ECU IG FUSE (RIGHT END OF DASH)
JUNCTION CONNECTOR
LEFT FRONT SEAT OUTER BELT ASSEMBLY (BASE OF LEFT "B" PILLAR)
LT GRN WIRE
MILLIMETER WAVE RADAR SENSOR (CENTER OF FRONT FASCIA)
PRE-COLLISION SYSTEM CANCEL SWITCH ASSEMBLY
RED WIRE
RIGHT FRONT SEAT OUTER BELT ASSEMBLY (BASE OF RIGHT "B" PILLAR)
SEAT BELT CONTROL ECU (LEFT SIDE OF LUGGAGE COMPT)
SKID CONTROL ECU (LEFT REAR OF ENGINE COMPT)
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component: -> Pre-collision circuit -> YEL WIRE
Wiring diagram yel (95 of 140)
17 SPEAKER
ADPG
AGND
ALO
ARO
ASGN
AUXO
BLK WIRE
BLU WIRE
BRN WIRE
GRN WIRE
HFL
LJB
LT BLU WIRE
MACC
MAP LIGHT ASSEMBLY
MCO-
MCSG
MICROPHONE
MULTI-MEDIA MODULE RECEIVER ASSEMBLY
PNK WIRE
RED WIRE
SHIELD
STEREO JACK ADAPTER ASSEMBLY
UDO+
UJSG
UPI
USB
USBG
USBV
VA-
VAL+
VAR+
VIO WIRE
VOR-
VOT+
W/ LEXUS ENFORM W/O LEXUS ENFORM
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component: -> Radio circuit (3 of 4) -> YEL WIRE
Wiring diagram yel (96 of 140)
-TW
1 2 3 4 5 6 7 8 9 10 11 12 (PINS 13 TO 20 NOT USED) SHIELD MCG MCI+
BLK WIRE
BLU WIRE
CTR +
FRONT SPEAKER ASSEMBLY 3 (17 SPEAKER)
GRN WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER SYSTEM
LEFT FRONT SPEAKER ASSEMBLY 1
LEFT FRONT SPEAKER ASSEMBLY 2
LEFT REAR SPEAKER ASSEMBLY
LEFT REAR SPEAKER ASSEMBLY 2
LT BLU WIRE
LT GRN WIRE
MCI-
OF LUGGAGE COMPT)
PNK WIRE
RAD 1 FUSE
RAD 2 FUSE
REAR SPEAKER ASSEMBLY 3
RED WIRE
RIGHT COWL SIDE J/B (RIGHT END OF DASH)
RIGHT FRONT SPEAKER ASSEMBLY 1
RIGHT FRONT SPEAKER ASSEMBLY 2
RIGHT REAR SPEAKER ASSEMBLY
RIGHT REAR SPEAKER ASSEMBLY 2
SHIELD
SL- SR- FL- FR- RL- RR-
SPEAKER
STEREO COMPONENT AMPLIFIER (RIGHT REAR CORNER
VIO WIRE
WFL- WFR-
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component: -> Radio circuit (4 of 4) -> YEL WIRE
Wiring diagram yel (97 of 140)
13 14 29 20 CANL CANH NSW STA
AGND CANL CANH
BATTERY
BLK WIRE
BLU WIRE
CERTIFICATION ECU (RIGHT END OF DASH)
COMPUTER DATA LINES SYSTEM
ECM (ENGINE CONTROL MODULE) (LEFT SIDE OF ENGINE COMPT)
ENGINE GND SWITCH
ENGINE ROOM R/B 1 (RIGHT REAR OF ENGINE COMPT)
GRN WIRE
HOT AT ALL TIMES
JUNCTION CONNECTOR
LT GRN WIRE
PARK/NEUTRAL POSITION SWITCH (TRANSMISSION)
RED WIRE
RIGHT END OF DASH)
ST FUSE
ST RELAY
STA STAR
STARTER ASSEMBLY
VIO WIRE
WHT WIRE
YEL WIRE
Go to component: -> Starting circuit -> YEL WIRE
Wiring diagram yel (98 of 140)
-SR -SL +SR +SL
ABFS
AIR BAG FUSE
AIR BAG SENSOR ASSEMBLY (UNDER REAR OF CENTER FLOOR CONSOLE)
BBL+
BCL+
BDL-
BLK WIRE
BLU WIRE
BUCKLE SWITCH
CANL PAON
COMPUTER DATA LINES SYSTEM
DK DK
GRN WIRE
GSW
LBE+ LSP+ BBL+ BBL-
LBE- LSP-
LEFT COWL SIDE J/B (LEFT END OF DASH) MAIN BODY ECU
LEFT CURTAIN SHIELD AIR BAG ASSEMBLY (NEAR TOP OF LEFT "B" PILLAR)
LEFT FRONT SEAT AIR BAG ASSEMBLY
LEFT FRONT SEAT INNER BELT (UNDER DRIVER'S SEAT)
LEFT REAR AIR BAG SENSOR (UNDER LEFT REAR SEAT)
LEFT REAR SIDE AIR BAG SQUIB (OUTER SIDE OF LEFT REAR SEAT)
LEFT SIDE AIR BAG SENSOR (IN LEFT "B" PILLAR)
P- P+ D+ D-
P-AB GSW PK+ PK-
PNK WIRE
RED WIRE
RIGHT COWL SIDE J/B (RIGHT END OF DASH)
SEAT POSITION AIR BAG SENSOR
SFL-
SRL-
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component: -> Supplemental restraint circuit (1 of 3) -> YEL WIRE
Wiring diagram yel (99 of 140)
AIR
ARON
BLK WIRE
GRN WIRE
GSW
ICR+
INSTRUMENT PANEL PASSENGER AIR BAG W/O DOOR ASSEMBLY
LEFT FRONT SEAT OUTER BELT (BASE OF LEFT "B" PILLAR)
LEFT REAR SEAT POINT 3 TYPE OUTER BELT ASSEMBLY (LEFT "C" PILLAR)
MULTI-MEDIA MODULE RECEIVER ASSEMBLY PASSENGER AIR BAG ON/OFF INDICATOR
RIGHT COWL SIDE J/B (RIGHT END OF DASH)
RIGHT CURTAIN SHIELD AIR BAG ASSEMBLY (NEAR TOP OF RIGHT "B" PILLAR)
RIGHT FRONT SEAT AIR BAG ASSEMBLY
RIGHT FRONT SEAT OUTER BELT ASSEMBLY (BASE OF RIGHT "B" PILLAR)
RIGHT REAR SEAT POINT 3 TYPE OUTER BELT ASSEMBLY (RIGHT "C" PILLAR)
RIGHT REAR SIDE AIR BAG SQUIB CIRCUIT (OUTER SIDE OF RIGHT REAR SEAT)
SFR-
SL-
SPIRAL CABLE (IN STEERING D+ COLUMN)
SR-
SRR+
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component: -> Supplemental restraint circuit (2 of 3) -> YEL WIRE
Wiring diagram yel (100 of 140)
13 26 CANH CANL
AIR BAG SENSOR ASSEMBLY (UNDER REAR OF CENTER FLOOR CONSOLE)
BBR+
BCR+
BDR
BLK WIRE
BLU WIRE
BUCKLE SWITCH
CAN I/F
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
ENGINE CONTROL MODULE (ECM) (LEFT SIDE OF ENGINE COMPT)
ENGINE ROOM R/B 1 (LEFT SIDE OF ENGINE COMPT)
FSR+ DIA GND FSR- +B IG
GAUGE FUSE
HOT AT ALL TIMES
ICR+
JUNCTION
LED DRIVER
LEFT REAR WEIGHT DETECTION SENSOR
OCCUPANT DETECTION ECU (UNDER FRONT PASSENGER'S SEAT)
ODS FUSE
PASSIVE RESTRAINTS SYSTEM
PR-
PRR-
RED WIRE
RIGHT COWL SIDE J/B (RIGHT END OF DASH)
RIGHT FRONT SEAT INNER BELT (UNDER FRONT PASSENGER'S SEAT)
RIGHT REAR AIR BAG SENSOR (UNDER RIGHT REAR SEAT)
RIGHT REAR WEIGHT DETECTION SENSOR
RIGHT SIDE AIR BAG SENSOR (IN RIGHT "B" PILLAR)
RIGHT SIDE DOOR AIR BAG SENSOR (IN RIGHT FRONT DOOR)
SFR-
SRR+
TELLTALES
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component: -> Supplemental restraint circuit (3 of 3) -> YEL WIRE
