Lexus GS IV (2011-2015) wiper/ wash cchg washer system Wiring diagram
This page shows the only wiring diagram for the component.wiper/ wash cchg washer system, which is found in the car Lexus GS IV (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram wiper/ wash cchg washer system (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
CCS HITP GND NAVIGATION SYSTEM
COMPUTER DATA LINES SYSTEM
DRIVING SUPPORT ECU ASSEMBLY (LEFT END OF DASH)
EFI MAIN FUSE
EFI MAIN RELAY 1
EFI MAIN RELAY 2
ENERGIZED LUGGAGE ROOM J/B 1 (LEFT SIDE OF FUSE LUGGAGE COMPT)
ENGINE ROOM J/B 1 (LEFT SIDE OF ENGINE COMPT)
F/PMP FUSE
FUEL PUMP CONTROL ECU (LEFT SIDE OF LUGGAGE COMPT)
FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
IGB
J/C
LEFT COWL SIDE J/B (LEFT END OF DASH)
LH ECU-IG FUSE
LT GRN WIRE
MILLIMETER WAVE RADAR SENSOR (CENTER OF FRONT FASCIA)
NETWORK GATEWAY ECU (RIGHT CENTER OF DASH)
PBSW SPSW
PNK WIRE
PRE-COLLISION SYSTEM CANCEL SWITCH
RED WIRE
RELAY ENERGIZED
SGND
STP+
VIO WIRE
WHT WIRE
WHT/BLK WIRE
WIPER/ WASH CCHG WASHER SYSTEM
WIPER/ WASHER WNKR WNKL SYSTEM
YEL WIRE
Go to component -> Cruise control circuit, with dynamic radar controls (1 of 3) -> WIPER/ WASH CCHG WASHER SYSTEM
