Lexus GS IV (2011-2015) wht Wiring diagram
This page shows the only wiring diagram for the component.wht, which is found in the car Lexus GS IV (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram wht (171 of 171)
13 26 32 11 50 34 CANH CANL IGSW SNWI SPCN SPSW
ANTI-LOCK BRAKES SYSTEM
BLK WIRE
BLU WIRE
BUZZER
CAN I/F
COMBINATION METER ASSEMBLY
COMBINATION SWITCH ASSEMBLY
COMPUTER DATA LINES SYSTEM
DRIVER DISPLAY
ECM (ENGINE CONTROL MODULE) (LEFT SIDE OF
ENGINE COMPT)
ENGINE ROOM R/B 1 (LEFT SIDE OF ENGINE COMPT)
FUSE
GAUGE FUSE
GRY WIRE
HOT AT ALL TIMES
HOT W/
J/C
LED DRIVER
LEFT COWL SIDE J/B (LEFT END OF DASH)
LT BLU WIRE
MPX-B FUSE
NORMAL
PADDLE SHIFT SWITCH
PNK SPORT WIRE
PNK WIRE
POWER MANAGEMENT CONTROL ECU (RIGHT END OF DASH)
RED WIRE
RIGHT COWL SIDE J/B (RIGHT END OF DASH)
SHIFT DOWN
SHIFT UP
SNOW
SPDI
SPIRAL CABLE (IN STEERING COLUMN)
STEERING PAD SWITCH ASSEMBLY
STOP FUSE
TELLTALES
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component: -> Transmission circuit (3 of 3) -> WHT WIRE
