Lexus GS IV (2011-2015) smog ventilation sensor Wiring diagrams

This page contains all the electrical diagrams for the component. smog ventilation sensor, in which he is found in the car Lexus GS IV (2011-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram smog ventilation sensor (1 of 2)

Wiring diagram smog ventilation sensor for Lexus GS IV (2011-2015)

Get access

AIR FUEL RATIO SENSOR (BANK 1 SENSOR 1) SHIELD AIR FUEL RATIO SENSOR (BANK 2 SENSOR 1) SHIELD BRN WIRE CANISTER PUMP MODULE COOLING FAN ECU CRANK POSITION SENSOR SHIELD ECM SHIELD ENGINE HOOD COURTESY SWITCH ENGINE OIL LEVEL IGNITION SENSOR COIL 6 FUEL PUMP INJECTOR ASSEMBLY DRIVER SHIELD SHIELD IGNITION COIL 1 IGNITION COIL 2 IGNITION COIL 3 IGNITION COIL 4 IGNITION COIL 5 JUNCTION KNOCK KNOCK CONTROL CONTROL SENSOR SENSOR (BANK 1) (BANK 2) SHIELD SHIELD LEFT FRONT FOG LIGHT ASSEMBLY LEFT HEADLIGHT ASSEMBLY MILLIMETER WAVE RADAR SENSOR ASSEMBLY NCA WIRE REAR OXYGEN SENSOR 2 (BANK 1 SENSOR 2) SHIELD REAR OXYGEN SENSOR 2 (BANK 2 SENSOR 2) SHIELD RIGHT FRONT FOG LIGHT ASSEMBLY RIGHT HEADLIGHT ASSEMBLY SMOG VENTILATION SENSOR SPIRAL CABLE (STEERING COLUMN) WHT/ BLK WIRE WHT/BLK WIRE

Go to component: -> Ground distribution circuit (2 of 6) -> SMOG VENTILATION SENSOR

Wiring diagram smog ventilation sensor (2 of 2)

Wiring diagram smog ventilation sensor for Lexus GS IV (2011-2015)

Get access

AIR FUEL RATIO SENSOR (BANK 1 SENSOR 1) SHIELD AIR FUEL RATIO SENSOR (BANK 2 SENSOR 1) SHIELD BLK WIRE BLK/ WHT WIRE BRN WIRE CANISTER PUMP MODULE COOLING FAN ECU CRANK POSITION SENSOR SHIELD DATA LINK CONNECTOR 3 ECM (ENGINE CONTROL MODULE) ENGINE HOOD COURTESY SWITCH ENGINE OIL LEVEL IGNITION SENSOR COIL 6 FUEL PUMP ASSEMBLY SHIELD IGNITION COIL 2 IGNITION COIL 4 IGNITION COIL 5 IGNITION IGNITION COIL 3 COIL 1 INJECTOR DRIVER SHIELD J/C KNOCK CONTROL SENSOR (BANK 1) SHIELD KNOCK CONTROL SENSOR (BANK 2) SHIELD LEFT FRONT FOG LIGHT ASSEMBLY LEFT HEADLIGHT ASSEMBLY MILLIMETER WAVE RADAR SENSOR NCA WIRE OXYGEN SENSOR (BANK 1 SENSOR 2) SHIELD OXYGEN SENSOR (BANK 2 SENSOR 2) SHIELD RIGHT FRONT FOG LIGHT ASSEMBLY RIGHT HEADLIGHT ASSEMBLY SMOG VENTILATION SENSOR WHT WIRE WHT/BLK WIRE WIRING HARNESS CONDENSER 2

Go to component: -> Ground distribution circuit (2 of 7) -> SMOG VENTILATION SENSOR
