Lexus GS IV (2011-2015) sliding roof switch Wiring diagram
This page shows the only wiring diagram for the component.sliding roof switch, which is found in the car Lexus GS IV (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sliding roof switch (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 PNK IG WIRE
13 14 CANL CANH
30 16 2 BECU
31 32 ALTB IG
5 15 LIN
BLK WIRE
BLU WIRE
BRN WIRE
CAN I/F
CLOSE
CLS
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DISPLAY DRIVER
DOWN
ENGINE ROOM R/B 1 (LEFT SIDE OF ENGINE COMPT)
GAUGE FUSE
GRN WIRE
HOT AT ALL TIMES
I/F LED DRIVER
ILLB
LEFT COWL SIDE J/B
LEFT FRONT DOOR COURTESY SWITCH (LEFT FRONT "B" PILLAR)
LH J/B-B FUSE
LH-IG FUSE
LILL
LT BLU WIRE
LT GRN WIRE
MAIN BODY ECU (LEFT END OF DASH)
MAP LIGHT ASSEMBLY
MPX-B FUSE
OPN
PNK WIRE
RED WIRE
RELAY ENERGIZED
S/ROOF FUSE
SLIDING ROOF CONTROL SWITCH
SLIDING ROOF SWITCH
SPEAKER
TELLTALES
UP CLS DWN OPN
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component: -> Power top/sunroof circuit -> SLIDING ROOF SWITCH
