Lexus GS IV (2011-2015) security horn relay Wiring diagrams
This page contains all the electrical diagrams for the component. security horn relay, in which he is found in the car Lexus GS IV (2011-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
security horn relay wiring diagram (1 of 4)
BLK WIRE
BRN WIRE
CENTER STOP LIGHT ASSEMBLY
EXCEPT 10-WAY SEAT POSITION 10-WAY SEAT POSITION
FUEL FUEL INJECTOR INJECTOR ASSEMBLY 4 ASSEMBLY 2 SHIELD SHIELD
FUEL INJECTOR ASSEMBLY 1 SHIELD
FUEL INJECTOR ASSEMBLY 3 SHIELD
FUEL INJECTOR ASSEMBLY 5 SHIELD
FUEL INJECTOR ASSEMBLY 6 SHIELD
JUNCTION
JUNCTION TERMINAL
LEFT "C" PILLAR)
LEFT BLIND SPOT MONITOR SENSOR
LEFT FRONT MULTIPLEX NETWORK DOOR ECU
LEFT FRONT SEAT HEATER ASSEMBLY
LEFT FRONT SEAT INNER BELT ASSEMBLY
LEFT POSITION CONTROL ECU ASSEMBLY
LEFT POSITION CONTROL ECU ASSEMBLY (EXCEPT 10-WAY SEAT POSITION)
LEFT REAR ABSORBER CONTROL ACTUATOR
LEFT REAR DOOR LOCK ASSEMBLY
LEFT REAR DOOR OUTSIDE HANDLE ASSEMBLY
LEFT REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY
LEFT REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY
LEFT REAR SEAT INNER W/ CENTER BELT ASSEMBLY
LEFT RIGHT REAR REAR COMBINATION COMBINATION LIGHT LIGHT ASSEMBLY ASSEMBLY
LEFT SEAT CLIMATE CONTROL BLOWER
LUGGAGE CLOSER MOTOR ASSEMBLY
NCA WIRE
PARKING FUEL BRAKE PUMP ECU CONTROL ASSEMBLY ECU
RELAY
SEAT BELT CONTROL ECU
SECURITY HORN RELAY
TRK BACK UP OPN RELAY RELAY
WHT WIRE
WHT/BLK WIRE
Go to component -> Ground distribution circuit (5 of 6) -> SECURITY HORN RELAY
security horn relay wiring diagram (2 of 4)
AC INV
BACK UP RELAY RELAY (HV)
BLK WIRE
BLK/ WHT WIRE
BRAKE CONTROL POWER SUPPLY
BRN WIRE
CENTER STOP LIGHT ASSEMBLY
CLIMATE CONTROL BLOWER
FUEL PARKING PUMP BRAKE CONTROL ECU ECU
J/C
JUNCTION TERMINAL
LEFT "C" PILLAR)
LEFT BATTERY COOLING BLOWER ASSEMBLY
LEFT BLIND SPOT MONITOR SENSOR
LEFT FRONT LEFT FRONT MULTIPLEX NETWORK SEAT INNER BELT DOOR ECU
LEFT FRONT SEAT HEATER ASSEMBLY
LEFT REAR ABSORBER CONTROL ACTUATOR
LEFT REAR COMBINATION LIGHT ASSEMBLY
LEFT REAR DOOR OUTSIDE HANDLE ASSEMBLY
LEFT REAR SEAT INNER BELT W/ CENTER ASSEMBLY
LEFT SEAT
POWER STEERING ECU SHIELDS
RELAY
RIGHT REAR COMBINATION LIGHT ASSEMBLY
SEAT BELT CONTROL ECU
SECURITY HORN RELAY
WHT WIRE
WHT/BLK WIRE
Go to component -> Ground distribution circuit (6 of 7) -> SECURITY HORN RELAY
security horn relay wiring diagram (3 of 4)
A/F INJ RELAY RELAY
AIR BAG FUSE
BACKUP FUSE
BACKUP RELAY
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
CRUISE NAVIGATION CONTROL SYSTEM SYSTEM
DOOR LOCKS, POWER WINDOWS, ANTI-THEFT, MEMORY SYSTEMS
ECU-B 3 FUSE
EFI MAIN 2 RELAY
EFI MAIN FUSE
EFI- MAIN 1 RELAY
ELECTRONIC POWER STEERING SYSTEM
ENGINE CONTROLS SYSTEM
ENGINE ROOM R/B 2 GAUGE (LEFT SIDE FUSE FUSE OF ENGINE COMPT)
EPS-IG FUSE
F/R DOOR FUSE
FROM ENGINE ROOM J/B 1 (DIAGRAM 1 OF 4)
FROM ENGINE ROOM R/B (DIAGRAM 1 OF 4)
FROM LEFT COWL SIDE J/B (DIAGRAM 4 OF 4)
FUSE
FUSE ENGINE CONTROLS SYSTEM
GRN WIRE
GRY WIRE
INJ IGN FUSE FUSE
INSTRUMENT CLUSTER SYSTEM
LEFT "C" PILLAR)
LEFT COWL SIDE J/B (BEHIND LEFT END OF DASH)
LT GRN WIRE
MULTIMEDIA FUSE FUSE
NAVIGATION SYSTEM
NAVIGATION, SOUND SYSTEMS
PASSIVE RESTRAINTS, AIR CONDITIONING SYSTEMS
PNK WIRE
POWER WINDOWS SYSTEM
PTL FUSE PSB FUSE
R/R DOOR FUSE
RAD 1 RAD 2 FUSE FUSE
RED WIRE
RELAY
RR ECU-IG FUSE
RR FR S/HTR S/HTR FUSE FUSE
RR IGI
RR J/B-B FUSE
SECURITY HORN RELAY
SHIFT INTERLOCK SYSTEM
SUPPLEMENTAL RESTRAINTS SYSTEM
TO CERTIFICATION ECU (DIAGRAM 3 OF 4)
TO RIGHT COWL SIDE J/B (DIAGRAM FROM ENGINE 3 OF 4) ROOM R/B (DIAGRAM 1 OF 4)
TRK OPN FUSE SECURITY FUSE
TRUNK, SEATS TAILGATE, SYSTEM FUEL DOORS SYSTEM
TRUNK, TAILGATE, FUEL DOORS, DOOR LOCKS, ANTI-THEFT SYSTEMS
VIO WIRE
WARNING, DOOR LOCKS, ANTI-THEFT SYSTEMS
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (2 of 4) -> SECURITY HORN RELAY
security horn relay wiring diagram (4 of 4)
1 2 3 4 5 6 7 8 IG
6 OF 7)
AC INV (HV) FUSE
AC INV (HV) RELAY
AIR CONDITIONING, SEATS, SOUND, NAVIGATION SYSTEMS
BACK UP RELAY
BACK-UP FUSE
BATT FAN (HV) FUSE
BATT FAN (HV) RELAY
BLK WIRE
BLU WIRE
CRUISE CONTROL SHIFT SYSTEM INTERLOCK SYSTEM
DC/DC-S (HV) FUSE
ECU-B 3 FUSE
ELECTRONIC POWER STEERING SYSTEM
ENGINE CONTROLS SYSTEM
EPS-IG FUSE
FR S/HTR FUSE
FROM ENGINE ROOM R/B (DIAGRAM 2 OF 7)
FROM FUSIBLE LINK BLOCK (DIAGRAM 1 OF 7)
FROM LEFT COWL SIDE J/B (DIAGRAM 4 OF 7)
FROM PTL FUSE (DIAGRAM
GRN WIRE
GRY WIRE
J/C
LEFT "C" PILLAR)
LT GRN WIRE
NAVIGATION SYSTEM
PASSIVE RESTRAINTS SYSTEM
POWER OUTLET SOCKET ASSEMBLY
PTL FUSE
RED WIRE
RELAY
RR ECU-IG FUSE FUSE
RR J/B-B PSB SECURITY FUSE FUSE FUSE
RR S/HTR FUSE
SEATS SYSTEM
SECURITY HORN RELAY
SHIFT NTERLOCK SYSTEM
TO AC INV (HV) RELAY (DIAGRAM 6 OF 7)
TRK OPN DCM (HV) FUSE FUSE
TRUNK, TAILGATE, FUEL DOORS SYSTEM
VIO WIRE
VOLTAGE INVERTER ASSEMBLY
WARNING, DOOR LOCKS, ANTI-THEFT SYSTEMS SUPPLEMENTAL RESTRAINTS SYSTEM
WHT WIRE
WHT/BLK WIRE
Go to component -> Power distribution circuit (6 of 7) -> SECURITY HORN RELAY
