Lexus GS IV (2011-2015) right steering pad switch distance control Wiring diagram
This page shows the only wiring diagram for the component.right steering pad switch distance control, which is found in the car Lexus GS IV (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right steering pad switch distance control (1 of 1)
12 25 2 46 1 CANP CANN +B MREL BATT
24 25 PNK WIRE
4 1 MREL
ACCELERATOR PEDAL SENSOR (TOP OF ACCELERATOR PEDAL ASSEMBLY)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL MAIN SWITCH CRUISE CONTROL SWITCH
ECM (ENGINE CONTROL MODULE) (LEFT SIDE OF ENGINE COMPT)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
J/C
LEFT COWL SIDE J/B
LT GRN WIRE
M+ M- VCTA
MODE
NCA WIRE
ON-OFF +RES -SET
PNK WIRE
POWER MANAGEMENT CONTROL ECU (RIGHT END OF DASH)
RED WIRE
RIGHT COWL SIDE PANEL J/B (RIGHT END OF DASH)
RIGHT STEERING PAD SWITCH DISTANCE CONTROL
SPIRAL CABLE SUB-ASSEMBLY (STEERING COLUMN)
STEERING PAD SWITCH ASSEMBLY
STOP FUSE
STOP LIGHT SWITCH (BRAKE PEDAL BRACKET)
THROTTLE BODY W/ MOTOR ASSEMBLY (TOP REAR OF ENGINE)
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component: -> Cruise control circuit, with dynamic radar controls (2 of 3) -> RIGHT STEERING PAD SWITCH DISTANCE CONTROL
