Lexus GS IV (2011-2015) pnk auto lin Wiring diagram
This page shows the only wiring diagram for the component.pnk auto lin, which is found in the car Lexus GS IV (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pnk auto lin (1 of 1)
5 7 10 4 9 1 LED
AUTO
BDR
BDRJ
BLK WIRE
BLU WIRE
BRN WIRE
CPUB
DOWN
DOWN AUTO
GRN WIRE
GRY WIRE
LED
LEFT FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY (LEFT "B" PILLAR)
LEFT FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY (LEFT FRONT DOOR)
LEFT REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY
LIN
LT GRN WIRE
PNK AUTO LIN WIRE
PNK WIRE
PWE
RED WIRE
RIGHT FRONT MULTIPLEX NETWORK DOOR ECU (IN RIGHT FRONT DOOR)
RIGHT FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY (RIGHT FRONT DOOR)
RIGHT FRONT POWER WINDOW REGULATOR SWITCH ASSEMBLY
RIGHT REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY (RIGHT REAR DOOR)
RIGHT REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY
SGND
SIG
UP AUTO
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component: -> Power windows circuit (2 of 2) -> PNK AUTO LIN WIRE
