Lexus GS IV (2011-2015) mrel irel fpc Wiring diagram
This page shows the only wiring diagram for the component.mrel irel fpc, which is found in the car Lexus GS IV (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram mrel irel fpc (1 of 1)
A/C AMPLIFIER (BEHIND CENTER OF DASH)
A/F FUSE
A/F RELAY
A/T SHIFT POSITION INDICATOR (SHIFTING HOLE FRAME SUB-ASSEMBLY)
BATT IGSW
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
COOLING FANS SYSTEM
ECM (ENGINE CONTROL MODULE) (LEFT SIDE OF ENGINE COMPT)
ECOS
EDU FUSE
EFI 2 FUSE
EFI MAIN 2 RELAY
EFI MAIN FUSE
EFI- MAIN 1 RELAY
EFII
EFIO
ENGINE ROOM J/B 2 (LEFT SIDE OF ENGINE COMPT)
F/PMP FUSE
GRN WIRE
GRY WIRE
ID CODE BOX (BEHIND CENTER OF DASH)
INJ RELAY
LT BLU WIRE
LT GRN WIRE
MREL IREL FPC
NEO
NSW IMO IMI PNK WIRE
PNK WIRE
RED WIRE
RFC EPA
SPCN
SR SFTD SFTU CAND CANU CANN CANP CANL CANH
STA TC SNWI PWR
STARTING/CHARGING SYSTEM
STARTING/CHARGING SYSTEM COMPUTER DATA LINES SYSTEM
TACH SPSW PNK WIRE
VCPA SPD KSW
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component: -> Wiring diagram engine performance 3.5l (1 of 9) -> MREL IREL FPC
