Lexus GS IV (2011-2015) millimeter wave radar sensor assembly Wiring diagram

This page shows the only wiring diagram for the component.millimeter wave radar sensor assembly, which is found in the car Lexus GS IV (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram millimeter wave radar sensor assembly (1 of 1)

Wiring diagram millimeter wave radar sensor assembly for Lexus GS IV (2011-2015)

Get access

AIR FUEL RATIO SENSOR (BANK 1 SENSOR 1) SHIELD AIR FUEL RATIO SENSOR (BANK 2 SENSOR 1) SHIELD BRN WIRE CANISTER PUMP MODULE COOLING FAN ECU CRANK POSITION SENSOR SHIELD ECM SHIELD ENGINE HOOD COURTESY SWITCH ENGINE OIL LEVEL IGNITION SENSOR COIL 6 FUEL PUMP INJECTOR ASSEMBLY DRIVER SHIELD SHIELD IGNITION COIL 1 IGNITION COIL 2 IGNITION COIL 3 IGNITION COIL 4 IGNITION COIL 5 JUNCTION KNOCK KNOCK CONTROL CONTROL SENSOR SENSOR (BANK 1) (BANK 2) SHIELD SHIELD LEFT FRONT FOG LIGHT ASSEMBLY LEFT HEADLIGHT ASSEMBLY MILLIMETER WAVE RADAR SENSOR ASSEMBLY NCA WIRE REAR OXYGEN SENSOR 2 (BANK 1 SENSOR 2) SHIELD REAR OXYGEN SENSOR 2 (BANK 2 SENSOR 2) SHIELD RIGHT FRONT FOG LIGHT ASSEMBLY RIGHT HEADLIGHT ASSEMBLY SMOG VENTILATION SENSOR SPIRAL CABLE (STEERING COLUMN) WHT/ BLK WIRE WHT/BLK WIRE

Go to component: -> Ground distribution circuit (2 of 6) -> MILLIMETER WAVE RADAR SENSOR ASSEMBLY
