Lexus GS IV (2011-2015) left lumbar support motor Wiring diagram

This page shows the only wiring diagram for the component.left lumbar support motor, which is found in the car Lexus GS IV (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram left lumbar support motor (1 of 1)

Wiring diagram left lumbar support motor for Lexus GS IV (2011-2015)

Get access

BACK BLK WIRE BRN WIRE CANN CANP COMPUTER DATA LINES SYSTEM CPUB DOWN DRIVER'S SEAT GRN WIRE GRY WIRE LEFT FRONT LUMBAR POWER SEAT SWITCH LEFT LUMBAR SUPPORT MOTOR LEFT POWER SEAT SLIDE MOTOR (UNDER DRIVER'S SEAT) LEFT POWER SEAT TILT MOTOR LEFT SEAT MEMORY SWITCH LT BLU WIRE LT GRN WIRE MMRY MSWE O/P ORG/ WIRE PNK WIRE RED WIRE SET- VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE

Go to component: -> Driver"s memory seat circuit, 10-way driver seat (2 of 2) -> LEFT LUMBAR SUPPORT MOTOR
