Lexus GS IV (2011-2015) left cowl Wiring diagram

This page shows the only wiring diagram for the component.left cowl, which is found in the car Lexus GS IV (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram left cowl (1 of 1)

Wiring diagram left cowl for Lexus GS IV (2011-2015)

Get access

BACK SONAR OR CLEARANCE SONAR SWITCH ASSEMBLY BLK WIRE BLU WIRE BOF BOR CBZ EF CLEARANCE WARNING BUZZER (LOWER LEFT CENTER OF DASH) CLEARANCE WARNING ECU ASSEMBLY (LEFT END OF DASH) COMPUTER DATA LINES SYSTEM ENGINE ROOM R/B 1 (LEFT SIDE OF GAUGE FUSE ENGINE COMPT) GRN WIRE GRY WIRE LEFT COWL LEFT REAR CENTER ULTRASONIC SENSOR (BEHIND LEFT CENTER OF REAR FASCIA) LEFT REAR ULTRASONIC SENSOR (BEHIND LEFT END OF REAR FASCIA) LH IG FUSE SIDE J/B (LEFT END OF DASH) LT BLU WIRE LT GRN WIRE PNK SOR WIRE PNK WIRE RED WIRE RELAY ENERGIZED RIGHT REAR CENTER ULTRASONIC SENSOR (BEHIND RIGHT CENTER OF REAR FASCIA) RIGHT REAR ULTRASONIC SENSOR (BEHIND RIGHT END OF REAR FASCIA) SOF CLSW VIO WIRE WHT WIRE WHT/BLK WIRE

Go to component: -> Rear sonar circuit (1 of 2) -> LEFT COWL
