Lexus GS IV (2011-2015) gry Wiring diagrams

11 12 CANN CANP 13 12 24 STP 2 1 PNK PNK +B WIRE A/T SHIFT POSITION INDICATOR (SHIFTING HOLE FRAME SUB-ASSEMBLY) BLK WIRE BLU WIRE COMPUTER DATA LINES SYSTEM ECM (ENGINE CONTROL MODULE) (LEFT SIDE OF ENGINE COMPT) EFI FUSE EFI- MAIN 1 RELAY ENGINE ROOM J/B 2 (LEFT SIDE OF ENGINE COMPT) GNDA (-) GRN WIRE GRY WIRE HOT AT ALL TIMES HOT AT ALL TIMES ENGINE ROOM R/B 1 (RIGHT REAR OF ENGINE COMPT) INTEGRATION RELAY LT BLU WIRE NT- NT+ P/I-B 1 FUSE PNK WIRE RED WIRE TRANSMISSION REVOLUTION SENSOR (COUNTER GEAR) (TRANSMISSION) TRANSMISSION REVOLUTION SENSOR (TURBINE) (TRANSMISSION) WHT WIRE WHT/BLK WIRE YEL WIRE

BLK WIRE BLU WIRE DIODE (A/T SHIFT) FUSE GRN WIRE GRY WIRE HOT AT ALL TIMES LT BLU WIRE PADDLE SHIFT PARK/NEUTRAL POSITION SWITCH (TRANSMISSION) RED WIRE RELAY ENERGIZED RH ACC RELAY RH ECU-IG FUSE RIGHT COWL SIDE J/B (BEHIND RIGHT END OF DASH) SFTD SFTU SHIFT DOWN SHIFT UP SPIRAL CABLE SUB-ASSEMBLY (STEERING COLUMN) STARTING/ CHARGING SYSTEM STEERING PAD SWITCH ASSEMBLY SWITCH WHT WIRE WHT/BLK WIRE YEL WIRE

+S SI 14 25 11 CANL CANH BLK WIRE BLU WIRE BRAKE ACTUATOR ASSEMBLY (LEFT REAR CORNER OF ENGINE COMPT) CAN I/F SPEAKER COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM DISPLAY DRIVER ENGINE ROOM R/B 2 (LEFT SIDE OF ENGINE COMPT) ES IG+ FUSE GAUGE FUSE GRY WIRE HOT AT ALL TIMES LEFT COWL SIDE J/B (BEHIND LEFT END OF DASH) LED DRIVER LT BLU WIRE LT GRN WIRE MULTI- FUNCTION INDICATOR LAMP RED WIRE RELAY ENERGIZED RIGHT COWL SIDE J/B (BEHIND RIGHT END OF DASH) STOP FUSE STOP LIGHT SWITCH (BRAKE PEDAL BRACKET) TELLTALES VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE

2 3 4 5 SLU- SLU+ SLT- SLT+ BLK WIRE BLU WIRE BRN WIRE COMBINATION SWITCH ASSEMBLY COMPUTER DATA LINES SYSTEM ECM (ENGINE CONTROL MODULE) (LEFT SIDE OF ENGINE COMPT) ECO ECOS ELECTRONICALLY CONTROLLED TRANSMISSION SOLENOID (TRANSMISSION) GRN WIRE GRY WIRE LT BLU WIRE LT GRN WIRE NORMAL OIL ORG/ WIRE PNK 23 22 25 PWR SNWI SPCN WIRE PNK SPSW WIRE PNK WIRE RED WIRE SFTU SFTD SR SLT- SLU+ SNOW SPORT SWITCH VIO WIRE W/ ADAPTIVE VARIABLE SUSPENSION W/O ADAPTIVE VARIABLE SUSPENSION WHT WIRE WHT/BLK WIRE YEL WIRE

1 2 3 4 5 6 7 8 M- M+ 10 6 5 VT TSEN AUTO AUTO IND BLK WIRE BLU WIRE CAN I/F CANH CANL 28 29 COMPUTER DATA LINES SYSTEM COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM ECU-B 3 FUSE ELECTRIC PARKING BRAKE SWITCH ENGINE ROOM R/B 1 (LEFT SIDE OF ENGINE COMPT) EPB GAUGE FUSE GRN WIRE GRY WIRE HOT AT ALL TIMES HOT AT ALL TIMES FUSIBLE LINK EPB FUSE BLOCK (LEFT REAR OF LUGGAGE COMPT) HOT AT ALL TIMES LUGGAGE ROOM J/B 1 (LEFT SIDE OF LUGGAGE COMPT) HOT W/ IG AUTO PNK WIRE ILL ILL IND LED DRIVER LEFT COWL SIDE J/B (LEFT END OF DASH) LH ECU-IG FUSE LOCK LPA TX +B MPX-B FUSE NCA WIRE PARKING BRAKE ACTUATOR (LEFT REAR OF LUGGAGE COMPT) PARKING BRAKE ECU (LEFT SIDE OF LUGGAGE COMPT) PARKING LIGHT SWITCH ASSEMBLY PNK WIRE RED WIRE RELEASE RR ECU-IG FUSE TELLTALES TGND TGND 1 2 VIO WIRE VT TSEN WHT WIRE WHT/BLK WIRE YEL WIRE

13 14 CANL CANH 31 32 30 ALTB IG BECU 7 10 6 11 9 12 +B +5 CSEL ASEL DATA GND 7 12 CSWE 9 10 3 5 8 CANP CANN ASEL BLK WIRE BLU WIRE CERTIFICATION ECU (RIGHT END OF DASH) CLUTCH COMPUTER DATA LINES SYSTEM CPS+ CPSE CSEL CSG CSV PAWL SWG ENGINE ROOM R/B 1 (LEFT SIDE OF ENGINE COMPT) FUSE GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ LEFT COWL SIDE J/B (LEFT END OF DASH) LH J/B-B FUSE LH-IG FUSE LT BLU WIRE LUGGAGE CLOSER MOTOR ASSEMBLY (LEFT FRONT OF LUGGAGE COMPT) LUGGAGE COMPARTMENT DOOR LOCK ASSEMBLY (CENTER REAR OF LUGGAGE COMPT LID) LUGGAGE DOOR OPENING CANCEL LUGGAGE DOOR OPENING SWITCH ASSEMBLY LUGGAGE ELECTRICAL KEY SWITCH LUGGAGE ROOM J/B 1 (LEFT SIDE OF LUGGAGE COMPT) MAIN BODY ECU (LEFT END OF DASH) MONITORING SYSTEM RECEIVER ASSEMBLY) MPX-B FUSE OF DASH) ORG/ WIRE PAWL HAWL CLS FSW PNK ECUB GND WIRE PNK WIRE POWER TRUNK LID CLOSE SWITCH DOOR CONTROL SWITCH PTL FUSE RDAM RED WIRE RELAY ENERGIZED RIGHT COWL SIDE J/B (RIGHT END RLY 1 RELAY ENERGIZED RR ECU-IG FUSE RR J/B-B FUSE SWITCH ASSEMBLY TMSW TSW WHT WIRE WHT/BLK WIRE YEL WIRE

BLK WIRE BLU WIRE BRN WIRE CA+ CGND SHIELD COMPUTER DATA LINES SYSTEM DOOR LOCKS SYSTEM EAU GRN WIRE GRY WIRE GVIF HOT AT ALL TIMES HOT AT ALL TIMES RIGHT COWL ILL ILL INSTRUMENT CLUSTER SYSTEM LEFT COWL SIDE J/B (LEFT END OF DASH) LEFT STEERING PAD SWITCH LH-IG FUSE LT BLU WIRE LT GRN WIRE MIN MIN+ SGND MACC SHIELD MODE MULTI MEDIA FUSE MULTI-MEDIA MODULE RECEIVER ASSEMBLY NCA WIRE NIGHT VIEW ECU (RIGHT SIDE OF LUGGAGE COMPT) OFF HOOK ON HOOK PNK WIRE RED WIRE RH ACC RELAY RH ECU-IG FUSE RIGHT STEERING PAD SWITCH ROOF ANTENNA ASSEMBLY SEEK SEUC SHIELD SIDE J/B (RIGHT END OF DASH) FUSE SPIRAL CABLE SUB-ASSEMBLY (IN STEERING COLUMN) STEERING PAD SWITCH ASSEMBLY SUPPLEMENTAL RESTRAINTS SYSTEM SWG AIR ARON V+ V- VMTF VOICE VOICE RETURN VOLUME- W/ LEXUS ENFORM W/O LEXUS ENFORM WHT WIRE WHT/BLK WIRE YEL WIRE

BLK WIRE BLU WIRE BRN WIRE CB+ CGND COMPUTER DATA LINES SYSTEM CURT CV+ ENGINE ROOM R/B 1 (LEFT SIDE OF ENGINE COMPT) GRN WIRE GRY WIRE GVIF HOT AT ALL TIMES ILL LIGHTS SYSTEM INTERIOR LINES SYSTEM COMPUTER DATA LT BLU WIRE LT GRN WIRE MCI- MCO- MCVD MI+ MO- MUTE PNK WIRE REAR TELEVISION CAMERA (CENTER REAR OF LUGGAGE COMPT LID) RED WIRE REMOTE OPERATION SWITCH SGND SHIELD TV FUSE USB USBG USBV VMTI VOR- VOT+ W/ NAVIGATION W/O NAVIGATION WHT WIRE WHT/BLK WIRE WUI WUO YEL WIRE

ALT BLK WIRE BLU WIRE COMPUTER DATA LINES SYSTEM ENERGIZED LEFT COWL SIDE J/B LH IG (LEFT FUSE END OF DASH) ENGINE ROOM J/B 1 ENGINE ROOM J/B 1 (LEFT SIDE OF ENGINE COMPT) ENGINE ROOM R/B 1 (LEFT SIDE OF ENGINE COMPT) FRONT CONTROL SWITCH GNDA (-) GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ IGCT RELAY ENERGIZED IGCT 5 FUSE INTEGRATION RELAY LH J/B-B FUSE MAIN BODY ECU MPX-B FUSE P/I DC/DC FUSE PNK WIRE POWER MANAGEMENT CONTROL ECU (RIGHT END OF DASH) REAR CONTROL SWITCH REAR ECU SUNSHADE SWITCH REAR SUNSHADE RELAY (REAR WINDOW SHADE ASSEMBLY) (UNDER REAR PARCEL SHELF) REAR SUNSHADE SWITCH ASSEMBLY RED WIRE REV RSSH RSW SHAD SHIFT LEVER POSITION SENSOR (TRANSMISSION) WHT WIRE WHT/BLK WIRE YEL WIRE

22 24 16 LSWE KUL KL 3 7 8 1 SIG CANN CANP GND 7 32 11 10 30 6 ACTG IG 9 10 3 5 8 CANP CANN ACTD BECU TR+ BLK WIRE BLU WIRE CERTIFICATION ECU (RIGHT END OF DASH) COMPUTER DATA LINES SYSTEM D DOOR UNLOCK RELAY D/L 1 FUSE D/L 2 FUSE ENGINE ROOM FLLK (UNDER CENTER CONSOLE) FUEL LID LOCK W/ MOTOR ASSEMBLY (LEFT SIDE OF LUGGAGE COMPT) FUEL OPN RELAY GRN WIRE GRY WIRE HOT AT ALL TIMES HOT AT ALL TIMES LUGGAGE ROOM J/B 1 (LEFT SIDE OF LUGGAGE COMPT) TRK OPN FUSE LEFT FRONT DOOR LOCK ASSEMBLY (REAR OF LEFT FRONT DOOR) LEFT FRONT MULTIPLEX NETWORK DOOR ECU (IN LEFT FRONT DOOR) LH J/B-B FUSE LOCK LOCK UN- LT BLU WIRE LT GRN WIRE LUGGAGE COMPARTMENT DOOR LOCK ASSEMBLY (CENTER REAR OF LUGGAGE COMPT LID) LUGGAGE DOOR OPENING CANCEL LUGGAGE DOOR OPENING SWITCH ASSEMBLY LUGGAGE ELECTRICAL KEY SWITCH MAIN BODY ECU (LEFT END OF DASH) MPX-B FUSE ECU-B FUSE R/B 1 (LEFT SIDE OF ENGINE COMPT) PNK 19 13 14 LGCY CANL CANH WIRE PNK PNK WIRE PNK WIRE POWER CHANGE RELAY RED WIRE RELAY ENERGIZED LEFT COWL SIDE J/B LH-IG FUSE (LEFT END OF DASH) RIGHT COWL SIDE J/B (RIGHT END OF DASH) SWITCH ASSEMBLY TMSW TSW TRK OPN RELAY VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE
