Lexus GS IV (2011-2015) gndb drlr tlp hlhr Wiring diagram
This page shows the only wiring diagram for the component.gndb drlr tlp hlhr, which is found in the car Lexus GS IV (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram gndb drlr tlp hlhr (1 of 1)
BLK WIRE
BLU WIRE
CAN I/F
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DISPLAY DRIVER
DRLL
ENGINE ROOM J/B 1 (LEFT SIDE OF ENGINE COMPT)
ENGINE ROOM J/B 1 (LEFT SIDE OF ENGINE COMPT) ALT
ENGINE ROOM R/B 1 (LEFT SIDE OF ENGINE COMPT)
FFG DRL HLHS TAIL
FFGL FFGR
FUSE
GAUGE FUSE
GNDA (-)
GNDB DRLR TLP HLHR
GRN WIRE
GRY WIRE
H-LP LO RELAY
HLHL
HOT AT ALL TIMES
INTEGRATION RELAY
LED DRIVER
LEFT HEADLIGHT ASSEMBLY LO HI
LH-LO H-LP FUSE
LT GRN WIRE
P/I DC/DC
RED WIRE
RELAY ENERGIZED
RH-LO H-LP FUSE
RIGHT HEADLIGHT ASSEMBLY LO HI
SPEAKER
TELLTALES
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component: -> Headlamps circuit (2 of 2) -> GNDB DRLR TLP HLHR
