Lexus GS IV (2011-2015) fsr+ dia gnd fsr- +b ig Wiring diagram
This page shows the only wiring diagram for the component.fsr+ dia gnd fsr- +b ig, which is found in the car Lexus GS IV (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fsr+ dia gnd fsr- +b ig (1 of 1)
13 26 CANH CANL
AIR BAG SENSOR ASSEMBLY (UNDER REAR OF CENTER FLOOR CONSOLE)
BBR+
BCR+
BDR
BLK WIRE
BLU WIRE
BUCKLE SWITCH
CAN I/F
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
ENGINE CONTROL MODULE (ECM) (LEFT SIDE OF ENGINE COMPT)
ENGINE ROOM R/B 1 (LEFT SIDE OF ENGINE COMPT)
FSR+ DIA GND FSR- +B IG
GAUGE FUSE
HOT AT ALL TIMES
ICR+
JUNCTION
LED DRIVER
LEFT REAR WEIGHT DETECTION SENSOR
OCCUPANT DETECTION ECU (UNDER FRONT PASSENGER'S SEAT)
ODS FUSE
PASSIVE RESTRAINTS SYSTEM
PR-
PRR-
RED WIRE
RIGHT COWL SIDE J/B (RIGHT END OF DASH)
RIGHT FRONT SEAT INNER BELT (UNDER FRONT PASSENGER'S SEAT)
RIGHT REAR AIR BAG SENSOR (UNDER RIGHT REAR SEAT)
RIGHT REAR WEIGHT DETECTION SENSOR
RIGHT SIDE AIR BAG SENSOR (IN RIGHT "B" PILLAR)
RIGHT SIDE DOOR AIR BAG SENSOR (IN RIGHT FRONT DOOR)
SFR-
SRR+
TELLTALES
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component: -> Supplemental restraint circuit (3 of 3) -> FSR+ DIA GND FSR- +B IG
