Lexus GS IV (2011-2015) efi main 2 relay Wiring diagrams
This page contains all the electrical diagrams for the component. efi main 2 relay, in which he is found in the car Lexus GS IV (2011-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram efi main 2 relay (1 of 3)
A/F INJ RELAY RELAY
AIR BAG FUSE
BACKUP FUSE
BACKUP RELAY
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
CRUISE NAVIGATION CONTROL SYSTEM SYSTEM
DOOR LOCKS, POWER WINDOWS, ANTI-THEFT, MEMORY SYSTEMS
ECU-B 3 FUSE
EFI MAIN 2 RELAY
EFI MAIN FUSE
EFI- MAIN 1 RELAY
ELECTRONIC POWER STEERING SYSTEM
ENGINE CONTROLS SYSTEM
ENGINE ROOM R/B 2 GAUGE (LEFT SIDE FUSE FUSE OF ENGINE COMPT)
EPS-IG FUSE
F/R DOOR FUSE
FROM ENGINE ROOM J/B 1 (DIAGRAM 1 OF 4)
FROM ENGINE ROOM R/B (DIAGRAM 1 OF 4)
FROM LEFT COWL SIDE J/B (DIAGRAM 4 OF 4)
FUSE
FUSE ENGINE CONTROLS SYSTEM
GRN WIRE
GRY WIRE
INJ IGN FUSE FUSE
INSTRUMENT CLUSTER SYSTEM
LEFT "C" PILLAR)
LEFT COWL SIDE J/B (BEHIND LEFT END OF DASH)
LT GRN WIRE
MULTIMEDIA FUSE FUSE
NAVIGATION SYSTEM
NAVIGATION, SOUND SYSTEMS
PASSIVE RESTRAINTS, AIR CONDITIONING SYSTEMS
PNK WIRE
POWER WINDOWS SYSTEM
PTL FUSE PSB FUSE
R/R DOOR FUSE
RAD 1 RAD 2 FUSE FUSE
RED WIRE
RELAY
RR ECU-IG FUSE
RR FR S/HTR S/HTR FUSE FUSE
RR IGI
RR J/B-B FUSE
SECURITY HORN RELAY
SHIFT INTERLOCK SYSTEM
SUPPLEMENTAL RESTRAINTS SYSTEM
TO CERTIFICATION ECU (DIAGRAM 3 OF 4)
TO RIGHT COWL SIDE J/B (DIAGRAM FROM ENGINE 3 OF 4) ROOM R/B (DIAGRAM 1 OF 4)
TRK OPN FUSE SECURITY FUSE
TRUNK, SEATS TAILGATE, SYSTEM FUEL DOORS SYSTEM
TRUNK, TAILGATE, FUEL DOORS, DOOR LOCKS, ANTI-THEFT SYSTEMS
VIO WIRE
WARNING, DOOR LOCKS, ANTI-THEFT SYSTEMS
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (2 of 4) -> EFI MAIN 2 RELAY
Wiring diagram efi main 2 relay (2 of 3)
A/C AMPLIFIER (BEHIND CENTER OF DASH)
A/F FUSE
A/F RELAY
A/T SHIFT POSITION INDICATOR (SHIFTING HOLE FRAME SUB-ASSEMBLY)
BATT IGSW
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
COOLING FANS SYSTEM
ECM (ENGINE CONTROL MODULE) (LEFT SIDE OF ENGINE COMPT)
ECOS
EDU FUSE
EFI 2 FUSE
EFI MAIN 2 RELAY
EFI MAIN FUSE
EFI- MAIN 1 RELAY
EFII
EFIO
ENGINE ROOM J/B 2 (LEFT SIDE OF ENGINE COMPT)
F/PMP FUSE
GRN WIRE
GRY WIRE
ID CODE BOX (BEHIND CENTER OF DASH)
INJ RELAY
LT BLU WIRE
LT GRN WIRE
MREL IREL FPC
NEO
NSW IMO IMI PNK WIRE
PNK WIRE
RED WIRE
RFC EPA
SPCN
SR SFTD SFTU CAND CANU CANN CANP CANL CANH
STA TC SNWI PWR
STARTING/CHARGING SYSTEM
STARTING/CHARGING SYSTEM COMPUTER DATA LINES SYSTEM
TACH SPSW PNK WIRE
VCPA SPD KSW
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 3.5l (1 of 9) -> EFI MAIN 2 RELAY
Wiring diagram efi main 2 relay (3 of 3)
+BM
A/C AMPLIFIER (CENTER OF DASH)
A/F FUSE
A/F RELAY
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
E.F.I VACUUM SENSOR (LEFT REAR OF ENGINE)
ECM (ENGINE CONTROL MODULE) (LEFT SIDE OF ENGINE COMPT)
ECOS
EDU FUSE
EFI 2 FUSE
EFI MAIN 2 RELAY
EFI MAIN FUSE
EFI- MAIN 1 RELAY
ENGINE ROOM J/B 1 (LEFT
EPIM
EPR
F/PMP FUSE
FPD +
FPF
FUEL PRESSURE SENSOR (REAR OF ENGINE)
GRN WIRE
GRN/BLK WIRE
GRY WIRE
INJ RELAY
LT GRN WIRE
NE+
PIM
PNK PNK WIRE
PNK WIRE
RED WIRE
SIDE OF ENGINE COMPT)
THA
VCPM
VCPR
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 3.5l hybrid, engine controls circuit (2 of 7) -> EFI MAIN 2 RELAY
