Lexus GS IV (2011-2015) canl paon Wiring diagram
This page shows the only wiring diagram for the component.canl paon, which is found in the car Lexus GS IV (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram canl paon (1 of 1)
-SR -SL +SR +SL
ABFS
AIR BAG FUSE
AIR BAG SENSOR ASSEMBLY (UNDER REAR OF CENTER FLOOR CONSOLE)
BBL+
BCL+
BDL-
BLK WIRE
BLU WIRE
BUCKLE SWITCH
CANL PAON
COMPUTER DATA LINES SYSTEM
DK DK
GRN WIRE
GSW
LBE+ LSP+ BBL+ BBL-
LBE- LSP-
LEFT COWL SIDE J/B (LEFT END OF DASH) MAIN BODY ECU
LEFT CURTAIN SHIELD AIR BAG ASSEMBLY (NEAR TOP OF LEFT "B" PILLAR)
LEFT FRONT SEAT AIR BAG ASSEMBLY
LEFT FRONT SEAT INNER BELT (UNDER DRIVER'S SEAT)
LEFT REAR AIR BAG SENSOR (UNDER LEFT REAR SEAT)
LEFT REAR SIDE AIR BAG SQUIB (OUTER SIDE OF LEFT REAR SEAT)
LEFT SIDE AIR BAG SENSOR (IN LEFT "B" PILLAR)
P- P+ D+ D-
P-AB GSW PK+ PK-
PNK WIRE
RED WIRE
RIGHT COWL SIDE J/B (RIGHT END OF DASH)
SEAT POSITION AIR BAG SENSOR
SFL-
SRL-
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component: -> Supplemental restraint circuit (1 of 3) -> CANL PAON
