Lexus GS IV (2011-2015) brake control power supply Wiring diagram
This page shows the only wiring diagram for the component.brake control power supply, which is found in the car Lexus GS IV (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram brake control power supply (1 of 1)
AC INV
BACK UP RELAY RELAY (HV)
BLK WIRE
BLK/ WHT WIRE
BRAKE CONTROL POWER SUPPLY
BRN WIRE
CENTER STOP LIGHT ASSEMBLY
CLIMATE CONTROL BLOWER
FUEL PARKING PUMP BRAKE CONTROL ECU ECU
J/C
JUNCTION TERMINAL
LEFT "C" PILLAR)
LEFT BATTERY COOLING BLOWER ASSEMBLY
LEFT BLIND SPOT MONITOR SENSOR
LEFT FRONT LEFT FRONT MULTIPLEX NETWORK SEAT INNER BELT DOOR ECU
LEFT FRONT SEAT HEATER ASSEMBLY
LEFT REAR ABSORBER CONTROL ACTUATOR
LEFT REAR COMBINATION LIGHT ASSEMBLY
LEFT REAR DOOR OUTSIDE HANDLE ASSEMBLY
LEFT REAR SEAT INNER BELT W/ CENTER ASSEMBLY
LEFT SEAT
POWER STEERING ECU SHIELDS
RELAY
RIGHT REAR COMBINATION LIGHT ASSEMBLY
SEAT BELT CONTROL ECU
SECURITY HORN RELAY
WHT WIRE
WHT/BLK WIRE
Go to component -> Ground distribution circuit (6 of 7) -> BRAKE CONTROL POWER SUPPLY
