Lexus GS IV (2011-2015) back sonar or clearance sonar switch assembly Wiring diagrams
This page contains all the electrical diagrams for the component. back sonar or clearance sonar switch assembly, in which he is found in the car Lexus GS IV (2011-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
back sonar or clearance sonar switch assembly wiring diagram (1 of 2)
BACK SONAR OR CLEARANCE SONAR SWITCH ASSEMBLY
BLK WIRE
BLK/WHT WIRE
BLU WIRE
COMPT)
CONSOLE BOX ILLUMINATION LIGHT ASSEMBLY
DOOR LOCK, UNLOCK SWITCH
ENGINE ROOM J/B 1 (LEFT SIDE OF ENGINE
GNDA (-)
GRN WIRE
INTEGRATION RELAY
LT GRN WIRE
MIRROR ADJUST SWITCH
MIRROR R/L SELECT SWITCH
MIRROR RETRACT SWITCH
MULTI-MEDIA MODULE RECEIVER ASSEMBLY
MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY
PNK WIRE
PNL
PNLS
REAR INSTRUMENT CONTROL PANEL REGISTER SWITCH ASSEMBLY 1
RED WIRE
REFRESHING SEAT SWITCH
RIGHT FRONT POWER WINDOW REGULATOR SWITCH ASSEMBLY
TAIL
VIO WIRE
WHT WIRE
WHT/ BLK WIRE
WHT/BLK WIRE
WINDOW LOCK SWITCH
Go to component -> Instrument illumination circuit (2 of 4) -> BACK SONAR OR CLEARANCE SONAR SWITCH ASSEMBLY
back sonar or clearance sonar switch assembly wiring diagram (2 of 2)
BACK SONAR OR CLEARANCE SONAR SWITCH ASSEMBLY
BLK WIRE
BLU WIRE
BOF
BOR
CBZ EF
CLEARANCE WARNING BUZZER (LOWER LEFT CENTER OF DASH)
CLEARANCE WARNING ECU ASSEMBLY (LEFT END OF DASH)
COMPUTER DATA LINES SYSTEM
ENGINE ROOM R/B 1 (LEFT SIDE OF
GAUGE FUSE ENGINE COMPT)
GRN WIRE
GRY WIRE
LEFT COWL
LEFT REAR CENTER ULTRASONIC SENSOR (BEHIND LEFT CENTER OF REAR FASCIA)
LEFT REAR ULTRASONIC SENSOR (BEHIND LEFT END OF REAR FASCIA)
LH IG FUSE SIDE J/B (LEFT END OF DASH)
LT BLU WIRE
LT GRN WIRE
PNK SOR WIRE
PNK WIRE
RED WIRE
RELAY ENERGIZED
RIGHT REAR CENTER ULTRASONIC SENSOR (BEHIND RIGHT CENTER OF REAR FASCIA)
RIGHT REAR ULTRASONIC SENSOR (BEHIND RIGHT END OF REAR FASCIA)
SOF CLSW
VIO WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Rear sonar circuit (1 of 2) -> BACK SONAR OR CLEARANCE SONAR SWITCH ASSEMBLY
