Lexus GS IV (2011-2015) 26 7 8 pnk mswe cann canp Wiring diagram
This page shows the only wiring diagram for the component.26 7 8 pnk mswe cann canp, which is found in the car Lexus GS IV (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 26 7 8 pnk mswe cann canp (1 of 1)
1 2 3 4 5 6 MR+ PEL- ISR+ PEL+ MR- ISR-
26 7 8 PNK MSWE CANN CANP WIRE
BACK
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
GRN WIRE
GRY WIRE
ISR+
ISRG
LFT+ SLD- FRV-
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PEL+
PELG
PNK WIRE
RED WIRE
RIGHT FRONT MULTIPLEX NETWORK DOOR ECU
RIGHT POSITION CONTROL ECU (UNDER FRONT PASSENGER'S SEAT)
RIGHT POWER SEAT PELVIC SUPPORT MOTOR
RIGHT POWER SEAT RECLINING MOTOR
RIGHT POWER SEAT SIDE SUPPORT MOTOR
RIGHT POWER SEAT SLIDE MOTOR
RIGHT SEAT MEMORY SWITCH
SET-
SISR
SLD+ FRV+ RCL+ LFT- RCL-
SPEL
VCC
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component: -> Passenger"s memory seat circuit (2 of 2) -> 26 7 8 PNK MSWE CANN CANP WIRE
