Lexus GS IV (2011-2015) 13 25 22 14 11 ffgo drl dim trly Wiring diagram

13 25 22 14 11 FFGO DRL DIM TRLY 31 32 ALTB IG 4 2 FRCY FLCY 6 13 14 27 5 8 30 29 28 21 20 22 RCTY CANL CANH FFOG HU HF TAIL HEAD AIR CONDITIONING SYSTEM AUTO AUTOMATIC LIGHT CONTROL SENSOR (UPPER RIGHT SIDE OF DASH) BLK WIRE BLU WIRE CLTB CLTE CLTS CLTS CLTB CLTE DIMMER SWITCH ENGINE ROOM R/B 1 (LEFT SIDE OF ENGINE COMPT) FOG LIGHT SWITCH GRN WIRE GRY WIRE H-LP LO FUSE HEAD HEADLIGHT DIMMER SWITCH ASSEMBLY HOT AT ALL TIMES LCTY LEFT COWL SIDE J/B LEFT FRONT FOG LIGHT ASSEMBLY LH J/B-B FUSE LH-IG FUSE LIGHT CONTROL SWITCH LLEW RLEW LT BLU WIRE LT GRN WIRE MAIN BODY ECU (LEFT END OF DASH) MPX-B FUSE OFF P/I-B 1 FUSE PNK WIRE RED WIRE RELAY ENERGIZED RIGHT FRONT FOG LIGHT ASSEMBLY SOLAR SENSOR TAIL TSL TSR VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE
