Lexus GS IV (2011-2015) 1 4 3 shpe gnd Wiring diagram

1 4 3 SHDE GND 1 4 3 SHPE GND 1 6 7 +B 10 3 14 PNK PNK WIRE 17 31 18 TFAL SG TFAR 21 30 31 PNK RLIN SHPE SHDE WIRE 3 4 CANH CANL 5 9 PNK RLIN WIRE A/C AMPLIFIER (CENTER OF DASH) BLU WIRE COMPUTER DATA LINES SYSTEM ENGINE ROOM R/B 1 FUSE GRN WIRE GRY WIRE HOT AT ALL TIMES LEFT REAR SEAT BACK HEATER ASSEMBLY LEFT REAR SEAT HEATER ASSEMBLY LEFT SEAT HEATER CONTROL LT GRN WIRE LUGGAGE ROOM J/B 1 MPX-B (LEFT SIDE FUSE OF ENGINE COMPT) PNK WIRE REAR CONTROL SWITCH RED WIRE RH ACC RELAY RIGHT COWL SIDE J/B (RIGHT END OF DASH) RIGHT REAR SEAT BACK HEATER ASSEMBLY RIGHT REAR SEAT HEATER ASSEMBLY RIGHT SEAT HEATER CONTROL RR ECU-IG FUSE RR S/HTR FUSE SEAT HEATER SWITCH TFAL TFAR VIO WIRE W/ NIGHT VIEW SYSTEM W/O NIGHT VIEW SYSTEM WHT WIRE WHT/BLK WIRE YEL WIRE
