Memory power tilt & power telescopic circuit for Lexus GS III facelift (2007-2011)

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 TIM- +B 1 2 3 4 5 TIM+ TIM- GND VCI TIS 3.5L 4.6L 4.6L 3.5L 8 3 2 MM BLK WIRE BLU WIRE BODY ECU BRN WIRE CERTIFICATION ECU (RIGHT REAR CORNER OF LUGGAGE COMPT) COMPUTER DATA LINES SYSTEM DOWN DRIVER'S SEAT MEMORY SWITCH (IF EQUIPPED) ECU-IG RH FUSE ENGINE CONTROL MODULE (AT LEFT SIDE OF ENGINE COMPT) ENGINE ROOM R/B 1 (RIGHT REAR OF ENGINE COMPT) GATEWAY ECU (BEHIND RIGHT SIDE OF DASH) GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRY WIRE HEADLAMP DIMMER SWITCH ASSEMBLY HOT AT ALL TIMES LEFT COWL SIDE J/B (BEHIND LEFT SIDE OF DASH) LH-IG FUSE LONG LT BLU WIRE LT GRN WIRE MPX-B FUSE MSW MSWE ORG/ WIRE PARK/NEUTRAL POSITION SWITCH (ON TRANSMISSION) PNK COMPUTER DATA LINES SYSTEM WIRE PNK WIRE POWER SOURCE CONTROL ECU (BEHIND RIGHT SIDE OF DASH) POWER WINDOW MASTER SWITCH RED WIRE RELAY RIGHT CENTER J/B (BEHIND RIGHT SIDE OF DASH) RIGHT COWL SIDE J/B (BEHIND RIGHT SIDE OF DASH) SET- SHORT TELESCOPIC MOTOR TELESCOPIC SENSOR TEM TI, TE FUSE TILT MOTOR TILT MOTOR (UNDER LEFT SIDE OF DASH) TILT SENSOR TILT, TELESCOPIC ECU (TOP RIGHT SIDE OF STEERING COLUMN) TILT, TELESCOPIC SWITCH VCE TES VCI TIS IG ECUB TIM+ GND VIO WIRE WHT WIRE WHT/BLK WIRE WINDSHIELD WIPER SWITCH ASSEMBLY YEL WIRE
