Lexus GS III facelift (2007-2011) pnk ne- Wiring diagram
This page shows the only wiring diagram for the component.pnk ne-, which is found in the car Lexus GS III facelift (2007-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pnk ne- (1 of 1)
3.5L
30 31 13 26 38 MPX+ MPX- PRE
4.6L
4.6L 3.5L SUB FAN MOTOR
A/C AMPLIFIER (BEHIND CENTER RIGHT OF DASH)
A/C PRESSURE SENSOR (LEFT FRONT OF ENGINE COMPT)
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
CAN L
COMPUTER DATA LINES SYSTEM
COOLING FAN ECU
CRANKSHAFT POSITION SENSOR (4.6L) (LEFT FRONT OF ENGINE)
ENGINE CONTROL MODULE (AT LEFT SIDE OF ENGINE COMPT)
ENGINE ROOM J/B 1 (RIGHT REAR OF ENGINE COMPT)
ENGINE ROOM R/B 1 (RIGHT REAR OF ENGINE COMPT)
FAN MAIN RELAY
FUSE
GATEWAY ECU (BEHIND RIGHT SIDE OF DASH)
GRN WIRE
GRN/YEL WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT COWL SIDE J/B (BEHIND LEFT SIDE OF DASH)
LH-IG FUSE
LT BLU WIRE
LT GRN WIRE
MAIN FAN MOTOR
NCA WIRE
NE+
PNK NE- WIRE
PNK WIRE
POWER SOURCE CONTROL ECU (BEHIND RIGHT SIDE OF DASH)
RED (OR RED/BLU) WIRE
RED WIRE
RELAY
RFC
SG-2
VIO WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> Cooling fan circuit -> PNK NE- WIRE
