Lexus GS III facelift (2007-2011) lin auto led Wiring diagram
This page shows the only wiring diagram for the component.lin auto led, which is found in the car Lexus GS III facelift (2007-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lin auto led (1 of 1)
3 6 4 5 20 8 9 1 2 SIG BDR CPUB BDRJ SGND
4 3 6 5 8 9 20 1 2 CPUB SIG BDR BDRJ
AUTO
BLK WIRE
BLU WIRE
BODY ECU
BRN WIRE
COMPUTER DATA LINES SYSTEM
DOOR FUSE
ENGINE ROOM R/B 1 (RIGHT REAR OF ENGINE COMPT)
GATEWAY ECU (BEHIND RIGHT SIDE OF DASH)
GND PWE
GRN WIRE
GRN/RED WIRE
GRY WIRE
HOT AT ALL TIMES
LED
LIN
LIN AUTO LED
LT BLU WIRE
LT GRN WIRE
MPX-B FUSE
ORG/ WIRE
PNK WIRE
RED WIRE
RELAY
RH-IG FUSE
RIGHT COWL SIDE J/B
RIGHT FRONT
RIGHT FRONT DOOR ECU (IN RIGHT FRONT DOOR)
RIGHT FRONT POWER WINDOW REGULATOR MOTOR (IN RIGHT FRONT DOOR)
RIGHT FRONT POWER WINDOW SWITCH
RIGHT REAR
RIGHT REAR DOOR ECU (IN RIGHT REAR DOOR)
RIGHT REAR POWER WINDOW REGULATOR MOTOR (IN RIGHT REAR DOOR)
RIGHT REAR POWER WINDOW SWITCH
SGND GND PWE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Power windows circuit (2 of 2) -> LIN AUTO LED
