Lexus GS III facelift (2007-2011) door interior light switch Wiring diagram
This page shows the only wiring diagram for the component.door interior light switch, which is found in the car Lexus GS III facelift (2007-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram door interior light switch (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
DOOR INTERIOR LIGHT SWITCH
GRN WIRE
GRY WIRE
LEFT FRONT MAP LAMP
LEFT FRONT SEAT SPOT LAMP
LEFT READING LAMP
LEFT READING LAMP SWITCH
LT GRN WIRE
OFF
ORG/ WIRE
OVERHEAD J/B (IN OVERHEAD CONSOLE)
PNK WIRE
REAR SEAT SPOT LAMP
RED WIRE
RIGHT FRONT MAP LAMP
RIGHT READING LAMP
RIGHT READING LAMP SWITCH
ROOM LAMP
SHIFT ILLUMINATION
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit (3 of 5) -> DOOR INTERIOR LIGHT SWITCH
